Hyundai Staria 2.2 CRDi Automatic Specs

(2021 - ) - Technical Specifications for Years 2021, 2022, 2023, 2024, 2025

Key Specs

Diesel

2199 cm³
134.2 cu-in

Inline 4

177 PS
175 HP / 130 kW

430 Nm
317 lb-ft

185 km/h
115 Mph

8.5 L/100 km
33 MPG UK
28 MPG US

Compare with another car

More pictures

Hyundai Staria 2.2 CRDi Automatic Body, Model and Production details

Body :	Minivan

Num. of Doors :	5 doors


Hyundai Staria 2.2 CRDi Automatic Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	D4HB

Fuel type :	Diesel

Fuel System :	Common Rail

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	2199 cm³ / 134.2 cu-in

Bore x Stroke :	85.4 x 96.0 mm 3.36 x 3.78 inches

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Horsepower :	177 PS / 175 HP / 130 kW @ 3800 rpm

Maximum torque :	430 Nm / 317 lb-ft @ 1500-2500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	8 speed Automatic


Hyundai Staria 2.2 CRDi Automatic Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Low WLTP:	11.1 L/100 km 25 MPG UK 21 MPG US

Fuel Consumption - Economy - Medium WLTP:	8.5 L/100 km 33 MPG UK 28 MPG US

Fuel Consumption - Economy - High WLTP:	7.2 L/100 km 39 MPG UK 33 MPG US

Fuel Consumption - Economy - Extra high WLTP:	8.6 L/100 km 33 MPG UK 27 MPG US

Fuel Consumption - Economy - Combined WLTP:	8.5 L/100 km 33 MPG UK 28 MPG US

Range (WLTP):	882 km / 548 miles

Fuel Tank Capacity :	75 L 19.8 US gallons 16.5 UK gallons

CO2 emissions WLTP :	222 g/km (Hyundai)

Emission standard :	Euro 6d - WLTP

Catalytic converter :	Particle Filter (with SCR cat. and NOx adsorber cat.)

Hyundai Staria 2.2 CRDi Automatic Performance

Top Speed :	185 km/h / 115 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	12.4 s


Hyundai Staria 2.2 CRDi Automatic Size, Dimensions, Aerodynamics and Weight

Wheelbase :	327.3 cm / 128.86 inches

Length :	525.3 cm / 206.81 inches

Width :	199.7 cm / 78.62 inches

Height :	199.0 cm / 78.35 inches

Front Axle :	172.1 cm / 67.76 inches

Rear Axle :	173.2 cm / 68.19 inches

Ground clearance :	18.6 cm / 7.32 inches

Max. Towing Capacity Weight :	1500 kg / 3307 lbs

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2367 kg / 5218 lbs

Weight/Power Output Ratio :	13.4 kg/hp


Hyundai Staria 2.2 CRDi Automatic Interior size, Dimensions

Num. of Seats :	9 seats

Trunk / Boot capacity :	831 L / 29.3 cu-ft

Trunk / Boot First Row :	1303 L / 46 cu-ft


Hyundai Staria 2.2 CRDi Automatic Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Front Tyres - Rims dimensions :	235/55 R18

Rear Tyres - Rims dimensions :	235/55 R18

Turning circle :	11.9 m / 39 feet

Front Suspension :	Independent. MacPherson. Coil Springs.

Rear Suspension :	Multi-link. Coil Springs.

What engine is in Hyundai Staria 2.2 CRDi Automatic?
The Hyundai Staria 2.2 CRDi Automatic has a Inline 4, Diesel engine with 2199 cm³ / 134.2 cu-in capacity.

How many horsepower (hp) does a 2021 Hyundai Staria 2.2 CRDi Automatic have?
The 2021 Hyundai Staria 2.2 CRDi Automatic has 177 PS / 175 bhp / 130 kW.

How much does a Hyundai Staria 2.2 CRDi Automatic weighs?
The Hyundai Staria 2.2 CRDi Automatic weighs 2367 Kg / 5218 lbs.

What is the top speed of a Hyundai Staria 2.2 CRDi Automatic?
The Hyundai Staria 2.2 CRDi Automatic top speed is 185 Km/h / 115 mph.

Is Hyundai Staria 2.2 CRDi Automatic All Wheel Drive (AWD)?
No, the Hyundai Staria 2.2 CRDi Automatic is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).

How fast is a Hyundai Staria 2.2 CRDi Automatic?
The Hyundai Staria 2.2 CRDi Automatic can reach 0 to 100 km/h (0 to 62 mph) in 12.4 seconds and has a top speed of 185 km/h.
