Ford S-Max Trend 1.6 TDCi 115HP 5 seats Specs

(2014 - ) Technical Specifications

Diesel

1560 cm³
95.2 cu-in

Inline 4

114 PS
112 HP / 84 kW

285 Nm
210 lb-ft

180 km/h
112 Mph

Ford S-Max Trend 1.6 TDCi 115HP 5 seats Body, Model and Production details

Generation :	S Max 1

Body :	-

Num. of Doors :	5 doors


Ford S-Max Trend 1.6 TDCi 115HP 5 seats Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Diesel

Fuel System :	Direct Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	1560 cm³ / 95.2 cu-in

Bore x Stroke :	75.0 x 88.3 mm 2.95 x 3.48 inches

Number of valves :	8 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	16.0

Horsepower :	114 PS / 112 HP / 84 kW @ 3600 rpm

Maximum torque :	285 Nm / 210 lb-ft @ 1750-2500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual


Ford S-Max Trend 1.6 TDCi 115HP 5 seats Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	5.9 L/100 km 48 MPG UK 40 MPG US

Fuel Consumption - Economy - Open road NEDC :	4.9 L/100 km 58 MPG UK 48 MPG US

Fuel Consumption - Economy - Combined NEDC :	5.2 L/100 km 54 MPG UK 45 MPG US

Range :	1346 km / 837 miles

Fuel Tank Capacity :	70 L 18.5 US gallons 15.4 UK gallons

CO2 emissions :	139 g/km (Ford)

Emission standard :	Euro V

Ford S-Max Trend 1.6 TDCi 115HP 5 seats Safety Ratings

Euro NCAP	Ford S-Max Trend 1.6 TDCi 115HP 5 seats Euro NCAP Safety Rating Adult: Pedestrian: Child: 5 of 5 2 of 5 4 of 5 Tested on: 2006

Ford S-Max Trend 1.6 TDCi 115HP 5 seats Performance

Top Speed :	180 km/h / 112 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	13.0 s


Ford S-Max Trend 1.6 TDCi 115HP 5 seats Size, Dimensions, Aerodynamics and Weight

Wheelbase :	285.0 cm / 112.2 inches

Length :	477.2 cm / 187.87 inches

Width :	188.4 cm / 74.17 inches

Height :	166.0 cm / 65.35 inches

Front Axle :	158.8 cm / 62.52 inches

Rear Axle :	160.5 cm / 63.19 inches

Aerodynamic drag coefficient - Cx :	0.31


Ford S-Max Trend 1.6 TDCi 115HP 5 seats Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	854 L / 30.2 cu-ft

Trunk / Boot First Row :	2100 L / 74.2 cu-ft


Ford S-Max Trend 1.6 TDCi 115HP 5 seats Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (300 mm / 11.81 inches)

Rear Brakes - Disc dimensions :	Discs (302 mm / 11.89 inches)

Front Tyres - Rims dimensions :	215/60 R16

Rear Tyres - Rims dimensions :	215/60 R16

Front Wheels Width :	6.5"

Rear Wheels Width :	6.5"

Steering :	Rack and pinion

Front Suspension :	MacPherson struts. Coil springs.

Rear Suspension :	Coil Springs.
