Ford S-Max Titanium 2.0 TDCi 140HP Powershift Specs

(2009 - ) Technical Specifications

Key Specs

Diesel

1997 cm³
121.9 cu-in

Inline 4

140 PS
138 HP / 103 kW

320 Nm
236 lb-ft

193 km/h
120 Mph

Compare with another car

More pictures

Ford S-Max Titanium 2.0 TDCi 140HP Powershift Body, Model and Production details

Generation :	S Max 1

Body :	-

Num. of Doors :	5 doors


Ford S-Max Titanium 2.0 TDCi 140HP Powershift Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Diesel

Engine Alignment :	Transverse

Engine displacement :	1997 cm³ / 121.9 cu-in

Bore x Stroke :	85 x 88 mm 3.35 x 3.46 inches

Number of valves :	16 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	17.9

Horsepower :	140 PS / 138 HP / 103 kW @ 4000 rpm

Maximum torque :	320 Nm / 236 lb-ft @ 1750-2750 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Automatic


Ford S-Max Titanium 2.0 TDCi 140HP Powershift Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	7.4 L/100 km 38 MPG UK 32 MPG US

Fuel Consumption - Economy - Open road NEDC :	5.2 L/100 km 54 MPG UK 45 MPG US

Fuel Consumption - Economy - Combined NEDC :	6 L/100 km 47 MPG UK 39 MPG US

Range :	1166 km / 725 miles

Fuel Tank Capacity :	70 L 18.5 US gallons 15.4 UK gallons

CO2 emissions :	159 g/km (Ford)

Ford S-Max Titanium 2.0 TDCi 140HP Powershift Safety Ratings

Euro NCAP	Ford S-Max Titanium 2.0 TDCi 140HP Powershift Euro NCAP Safety Rating Adult: Pedestrian: Child: 5 of 5 2 of 5 4 of 5 Tested on: 2006

Ford S-Max Titanium 2.0 TDCi 140HP Powershift Performance

Top Speed :	193 km/h / 120 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	10.9 s


Ford S-Max Titanium 2.0 TDCi 140HP Powershift Size, Dimensions, Aerodynamics and Weight

Wheelbase :	285.0 cm / 112.2 inches

Length :	477.2 cm / 187.87 inches

Width :	188.4 cm / 74.17 inches

Height :	166.0 cm / 65.35 inches

Aerodynamic drag coefficient - Cx :	0.313

Curb Weight :	1688 kg / 3721 lbs

Weight/Power Output Ratio :	12.1 kg/hp


Ford S-Max Titanium 2.0 TDCi 140HP Powershift Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	from 854 L / 30.2 cu-ft


Ford S-Max Titanium 2.0 TDCi 140HP Powershift Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (300 mm / 11.81 inches)

Rear Brakes - Disc dimensions :	Discs (302 mm / 11.89 inches)

Front Tyres - Rims dimensions :	225/50 R17

Rear Tyres - Rims dimensions :	225/50 R17

Front Suspension :	Independent MacPherson struts. Coil springs. Anti-roll bar.

Rear Suspension :	Independent. Coil Springs. Anti-roll bar.

What engine is in Ford S-Max Titanium 2.0 TDCi 140HP Powershift?
The Ford S-Max Titanium 2.0 TDCi 140HP Powershift has a Inline 4, Diesel engine with 1997 cm³ / 121.9 cu-in capacity.

How many horsepower (hp) does a 2009 Ford S-Max Titanium 2.0 TDCi 140HP Powershift have?
The 2009 Ford S-Max Titanium 2.0 TDCi 140HP Powershift has 140 PS / 138 bhp / 103 kW.

How much does a Ford S-Max Titanium 2.0 TDCi 140HP Powershift weighs?
The Ford S-Max Titanium 2.0 TDCi 140HP Powershift weighs 1688 Kg / 3721 lbs.

What is the top speed of a Ford S-Max Titanium 2.0 TDCi 140HP Powershift?
The Ford S-Max Titanium 2.0 TDCi 140HP Powershift top speed is 193 Km/h / 120 mph.

Is Ford S-Max Titanium 2.0 TDCi 140HP Powershift All Wheel Drive (AWD)?
No, the Ford S-Max Titanium 2.0 TDCi 140HP Powershift is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).

How fast is a Ford S-Max Titanium 2.0 TDCi 140HP Powershift?
The Ford S-Max Titanium 2.0 TDCi 140HP Powershift can reach 0 to 100 km/h (0 to 62 mph) in 10.9 seconds and has a top speed of 193 km/h.
