Biscayne 4th Gen Station Wagon Versions

Chevrolet Biscayne 4th Gen Station Wagon 396 V8 Turbo-Jet 325HP 3-speed Manual Specs

(1964 - 1965) - Technical Specifications for Years 1964, 1965

Petrol

6489 cm³
396 cu-in

V 8

330 PS
326 HP / 243 kW

556 Nm
410 lb-ft

Chevrolet Biscayne 4th Gen Station Wagon 396 V8 Turbo-Jet 325HP 3-speed Manual Body, Model and Production details

Generation :	Biscayne 4th Generation

Body :	Estate

Num. of Doors :	5 doors


Chevrolet Biscayne 4th Gen Station Wagon 396 V8 Turbo-Jet 325HP 3-speed Manual Engine Technical Data

Engine type - Number of cylinders :	V 8

Engine Code :	L35

Fuel type :	Petrol

Fuel System :	Carburetor

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	6489 cm³ / 396 cu-in

Bore x Stroke :	104.0 x 95.5 mm 4.09 x 3.76 inches

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	10.3

Horsepower :	330 PS / 326 HP / 243 kW @ 4800 rpm

Maximum torque :	556 Nm / 410 lb-ft @ 3200 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	3 speed Manual Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: Reverse Gear Ratio: 2.33 Final Drive Ratio: 3.31


Chevrolet Biscayne 4th Gen Station Wagon 396 V8 Turbo-Jet 325HP 3-speed Manual Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	91 L 24 US gallons 20 UK gallons

Chevrolet Biscayne 4th Gen Station Wagon 396 V8 Turbo-Jet 325HP 3-speed Manual Performance

Top Speed :	- km/h / - Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Chevrolet Biscayne 4th Gen Station Wagon 396 V8 Turbo-Jet 325HP 3-speed Manual Size, Dimensions, Aerodynamics and Weight

Wheelbase :	302.3 cm / 119.02 inches

Length :	541.8 cm / 213.31 inches

Width :	202.2 cm / 79.61 inches

Height :	144.0 cm / 56.69 inches

Front Axle :	161.3 cm / 63.5 inches

Rear Axle :	161.0 cm / 63.39 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1974 kg / 4352 lbs

Weight/Power Output Ratio :	6 kg/hp


Chevrolet Biscayne 4th Gen Station Wagon 396 V8 Turbo-Jet 325HP 3-speed Manual Interior size, Dimensions

Num. of Seats :	6 seats

Seat distribution :	3+3

Front legroom :	107.2 cm / 42.2 inches

Rear seat legroom :	100.3 cm / 39.49 inches

Front shoulder room :	156.0 cm / 61.42 inches

Rear shoulder room :	156.0 cm / 61.42 inches

Front head room :	99.3 cm / 39.09 inches

Rear head room :	96.0 cm / 37.8 inches

Front hip room :	162.1 cm / 63.82 inches

Rear hip room :	159.5 cm / 62.8 inches

Trunk / Boot capacity :	-


Chevrolet Biscayne 4th Gen Station Wagon 396 V8 Turbo-Jet 325HP 3-speed Manual Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Drums (- mm / - inches)

Rear Brakes - Disc dimensions :	Drums (- mm / - inches)

Front Tyres - Rims dimensions :	8.25/- R14

Rear Tyres - Rims dimensions :	8.25/- R14

Turning circle :	13.4 m / 44 feet

Front Suspension :	Independent. Wishbone. Coil Springs.

Rear Suspension :	Rigid Axle. Coil Springs.
