Ford Transit Custom Nugget L1 2024 320 2.0 EcoBlue 170HP AWD Auto Body, Model and Production details
|
|
| Generation : | Transit Custom 2 - 2024 New Model |
| Body : | Motorhome |
| Num. of Doors : | 4 doors |
Ford Transit Custom Nugget L1 2024 320 2.0 EcoBlue 170HP AWD Auto Engine Technical Data
|
|
| Engine type - Number of cylinders : | Inline 4 |
| Engine Code : | Ford EcoBlue BKAA |
| Fuel type : | Diesel |
| Fuel System : | Common Rail |
| Lubrication : |
See oil information  Ford Transit Custom Nugget L1 2024 320 2.0 EcoBlue 170HP AWD Auto Oil Specifications - Engine oil All Weather: OW30 OEM: WSS-M2C950-A API/ACEA: ACEA C2 Engine oil capacity (with filter): 8.3 L |
| Engine Alignment : | Transverse |
| Engine Position : | Front |
| Engine displacement : | 1996 cm3 / 121.8 cu-in |
| Bore x Stroke : |
84.0 x 90.0 mm 3.31 x 3.54 inches |
| Number of valves : | 16 Valves |
| Aspiration : | Turbo Intercooler |
| Compression Ratio : | 15.8 |
| Horsepower : |
170 PS / 168 HP / 125 kW @ 3500 rpm |
| Maximum torque : |
390 Nm / 287 lb-ft @ 1750-2500 rpm |
| Drive wheels - Traction - Drivetrain : | AWD |
| Transmission Gearbox - Number of speeds : |
8 speed Automatic
|
Ford Transit Custom Nugget L1 2024 320 2.0 EcoBlue 170HP AWD Auto Fuel Consumption (Economy), Emissions and Range
|
|
| Fuel Tank Capacity : |
55 L 14.5 US gallons 12.1 UK gallons |
| AdBlue Tank : |
20 L 5.3 US gallons 4.4 UK gallons |
| Emission standard : | Euro 6e |
| Catalytic converter : | Particle Filter (with SCR cat.) |
Ford Transit Custom Nugget L1 2024 320 2.0 EcoBlue 170HP AWD Auto Performance
|
|
| Top Speed : | - km/h / - Mph |
| Acceleration 0 to 100 km/h (0 to 62 mph) : | - s |
Ford Transit Custom Nugget L1 2024 320 2.0 EcoBlue 170HP AWD Auto Size, Dimensions, Aerodynamics and Weight
|
|
| Wheelbase : | 310.0 cm / 122.05 inches |
| Length : | 505.0 cm / 198.82 inches |
| Width : | 203.2 cm / 80 inches |
| Width with mirrors : | 227.5 cm / 89.57 inches |
| Height : | 206.0 cm / 81.1 inches |
| Front Axle : | 172.5 cm / 67.91 inches |
| Rear Axle : | 171.6 cm / 67.56 inches |
| Cargo box inside length : | 165.7 cm / 65.24 inches |
| Cargo box inside height : | 143.3 cm / 56.42 inches |
| Rear door width : | 140.0 cm / 55.12 inches |
| Rear door height : | 131.4 cm / 51.73 inches |
| Side door width : | 103.0 cm / 40.55 inches |
| Side door height : | 130.1 cm / 51.22 inches |
| Aerodynamic drag coefficient - Cx : | - |
Ford Transit Custom Nugget L1 2024 320 2.0 EcoBlue 170HP AWD Auto Interior size, Dimensions
|
|
| Num. of Seats : | 5 seats |
| Trunk / Boot capacity : | - |
Ford Transit Custom Nugget L1 2024 320 2.0 EcoBlue 170HP AWD Auto Brakes, Tires, Steering and Suspension
|
|||
| Front Brakes - Disc dimensions : |
Vented Discs (308 mm / 12.13 inches) |
||
| Rear Brakes - Disc dimensions : |
Discs (304 mm / 11.97 inches) |
||
| Front Tyres - Rims dimensions : | 215/60 R17 | ||
| Rear Tyres - Rims dimensions : | 215/60 R17 | ||
| Front Suspension : | MacPherson struts. Coil springs. Anti-roll bar. | ||
| Rear Suspension : | Independent. Coil Springs. Anti-roll bar. | ||
