Ford Kuga Active 2.5 FHEV CVT Specs

(2024 - ) - Technical Specifications for Years 2024, 2025

Key Specs

Hybrid / Petrol

2488 cm³
151.8 cu-in

Inline 4

180 PS
178 HP / 132 kW

196 km/h
122 Mph

5.4 L/100 km
52 MPG UK
44 MPG US

Compare with another car

More pictures

Ford Kuga Active 2.5 FHEV CVT Body, Model and Production details

Generation :	Kuga 2024 Facelift

Body :	SUV

Num. of Doors :	5 doors


Ford Kuga Active 2.5 FHEV CVT Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	BGDA

Fuel type :	Hybrid / Petrol

Fuel System :	MPI

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	2488 cm³ / 151.8 cu-in

Bore x Stroke :	89.0 x 100.0 mm 3.5 x 3.94 inches

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Horsepower :	152 PS / 150 HP / 112 kW @ 5500 rpm

Maximum torque :	200 Nm / 147 lb-ft @ 4500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	1 speed CVT


Ford Kuga Active 2.5 FHEV CVT Electric Engines Technical Data

Total System Power :	180 PS / 178 HP / 132 kW

Total System Torque :	- Nm / - lb-ft

Total electric power :	125 PS / 123 HP / 92 kW

Number of electric engines:	1

Electric engine type:	PSM - Permanent Magnet Synchronous Motor

Front Axle Electric Engine Power:	125 PS / 123 HP / 92 kW


Ford Kuga Active 2.5 FHEV CVT Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined WLTP:	5.4 L/100 km 52 MPG UK 44 MPG US

Range (WLTP):	999 km / 621 miles

Fuel Tank Capacity :	54 L 14.3 US gallons 11.9 UK gallons

Ford Kuga Active 2.5 FHEV CVT Battery Technical Data, Charging and Range

Battery type :	Lithium-ion

Battery capacity :	1.1 kWh

CO2 emissions WLTP :	124 g/km (Ford)

Emission standard :	Euro 6d - WLTP

Catalytic converter :	Y

Ford Kuga Active 2.5 FHEV CVT Performance

Top Speed :	196 km/h / 122 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	9.1 s


Ford Kuga Active 2.5 FHEV CVT Size, Dimensions, Aerodynamics and Weight

Wheelbase :	271.1 cm / 106.73 inches

Length :	464.5 cm / 182.87 inches

Width :	188.2 cm / 74.09 inches

Width with mirrors :	217.7 cm / 85.71 inches

Height :	168.3 cm / 66.26 inches

Front Axle :	159.9 cm / 62.95 inches

Rear Axle :	159.0 cm / 62.6 inches

Ground clearance :	19.1 cm / 7.52 inches

Approach angle (deg) :	20.0°

Departure angle (deg) :	24.7°

Max. Towing Capacity Weight :	1600 kg / 3527 lbs

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1689 kg / 3724 lbs

Weight/Power Output Ratio :	9.4 kg/hp


Ford Kuga Active 2.5 FHEV CVT Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	412 L / 14.5 cu-ft

Trunk / Boot First Row :	1534 L / 54.2 cu-ft


Ford Kuga Active 2.5 FHEV CVT Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (308 mm / 12.13 inches)

Rear Brakes - Disc dimensions :	Discs (302 mm / 11.89 inches)

Front Tyres - Rims dimensions :	225/60 R18

Rear Tyres - Rims dimensions :	225/60 R18

Front Wheels Width :	7.5"

Rear Wheels Width :	7.5"

Turning circle :	11.4 m / 37.4 feet

Front Suspension :	Independent. MacPherson. Coil Springs.

Rear Suspension :	Torsion beam. Coil Springs.

What engine is in Ford Kuga Active 2.5 FHEV CVT?
The Ford Kuga Active 2.5 FHEV CVT has a Inline 4, Hybrid / Petrol engine with 2488 cm³ / 151.8 cu-in capacity.
The Ford Kuga Active 2.5 FHEV CVT also have 1 electric engine(s) PSM - Permanent Magnet Synchronous Motor.

How many horsepower (hp) does a 2024 Ford Kuga Active 2.5 FHEV CVT have?
The 2024 Ford Kuga Active 2.5 FHEV CVT has 180 PS / 178 bhp / 132 kW.

How much does a Ford Kuga Active 2.5 FHEV CVT weighs?
The Ford Kuga Active 2.5 FHEV CVT weighs 1689 Kg / 3724 lbs.

What is the top speed of a Ford Kuga Active 2.5 FHEV CVT?
The Ford Kuga Active 2.5 FHEV CVT top speed is 196 Km/h / 122 mph.

Is Ford Kuga Active 2.5 FHEV CVT All Wheel Drive (AWD)?
No, the Ford Kuga Active 2.5 FHEV CVT is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).

How fast is a Ford Kuga Active 2.5 FHEV CVT?
The Ford Kuga Active 2.5 FHEV CVT can reach 0 to 100 km/h (0 to 62 mph) in 9.1 seconds and has a top speed of 196 km/h.
