Transporter T7 Plus LWB PanAmericana Versions

Volkswagen Transporter T7 Plus LWB PanAmericana 2.0 TDI 150HP 4MOTION Auto Specs

(2025 - ) - Technical Specifications for 2025

Diesel

1995 cm³
121.7 cu-in

Inline 4

150 PS
148 HP / 110 kW

360 Nm
265 lb-ft

Volkswagen Transporter T7 Plus LWB PanAmericana 2.0 TDI 150HP 4MOTION Auto Body, Model and Production details

Generation :	Transporter T7 - 2025 New Model

Body :	Van

Num. of Doors :	4 doors


Volkswagen Transporter T7 Plus LWB PanAmericana 2.0 TDI 150HP 4MOTION Auto Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	Ford Diesel EcoBlue

Fuel type :	Diesel

Fuel System :	Common Rail

Lubrication :	See oil information Volkswagen Transporter T7 Plus LWB PanAmericana 2.0 TDI 150HP 4MOTION Auto Oil Specifications - Engine oil All Weather: 0W30 OEM: WSS-M2C950-A API/ACEA: ACEA C2 Engine oil capacity (with filter): 8.3 L

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	1995 cm³ / 121.7 cu-in

Bore x Stroke :	84.01 x 90.03 mm 3.31 x 3.54 inches

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	16.5

Horsepower :	150 PS / 148 HP / 110 kW @ 3500 rpm

Maximum torque :	360 Nm / 265 lb-ft @ 1500-2500 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	8 speed Automatic


Volkswagen Transporter T7 Plus LWB PanAmericana 2.0 TDI 150HP 4MOTION Auto Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	55 L 14.5 US gallons 12.1 UK gallons

AdBlue Tank :	20 L 5.3 US gallons 4.4 UK gallons

Catalytic converter :	Particle Filter (with SCR cat.)

Volkswagen Transporter T7 Plus LWB PanAmericana 2.0 TDI 150HP 4MOTION Auto Performance

Top Speed :	- km/h / - Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	14.7 s


Volkswagen Transporter T7 Plus LWB PanAmericana 2.0 TDI 150HP 4MOTION Auto Size, Dimensions, Aerodynamics and Weight

Wheelbase :	350.0 cm / 137.8 inches

Length :	545.0 cm / 214.57 inches

Width :	203.2 cm / 80 inches

Width with mirrors :	227.5 cm / 89.57 inches

Height :	196.6 cm / 77.4 inches

Front Axle :	172.5 cm / 67.91 inches

Rear Axle :	171.6 cm / 67.56 inches

Cargo box inside length :	200.4 cm / 78.9 inches

Cargo box inside height :	142.5 cm / 56.1 inches

Cargo width :	177.7 cm / 69.96 inches

Max. width at wheelhouse :	139.2 cm / 54.8 inches

Rear door width :	140.0 cm / 55.12 inches

Rear door height :	131.6 cm / 51.81 inches

Side door width :	103.0 cm / 40.55 inches

Side door height :	130.1 cm / 51.22 inches

Max. Towing Capacity Weight :	2500 kg / 5512 lbs

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2194 kg / 4837 lbs

Weight/Power Output Ratio :	14.6 kg/hp


Volkswagen Transporter T7 Plus LWB PanAmericana 2.0 TDI 150HP 4MOTION Auto Interior size, Dimensions

Num. of Seats :	6 seats

Trunk / Boot capacity :	-


Volkswagen Transporter T7 Plus LWB PanAmericana 2.0 TDI 150HP 4MOTION Auto Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (308 mm / 12.13 inches)

Rear Brakes - Disc dimensions :	Vented Discs (304 mm / 11.97 inches)

Front Tyres - Rims dimensions :	215/60 R17

Rear Tyres - Rims dimensions :	215/60 R17

Turning circle :	13.8 m / 45.3 feet

Front Suspension :	MacPherson struts. Coil springs. Anti-roll bar.

Rear Suspension :	Independent. Coil Springs. Anti-roll bar.
