Make

Escudo 1997 Versions

- 1.6 3-Door 2WD Automatic (2000)- 1600JM 3-Door (1997)- 1600JM 3-Door Automatic (1997)- 1600JM 5-Door (1997)- 1600JM 5-Door Automatic (1997)- 1600JZ 3-Door (1997)- 1600JZ 3-Door Automatic (1997)- 1600JZ 5-Door (1997)- 1600JZ 5-Door Automatic (1997)- 2000JM 3-Door Automatic (1997)- 2000JM 5-Door Automatic (1997)

Suzuki Escudo 1997 1600JM 5-Door Automatic Specs

(1997 - 1999) - Technical Specifications for Years 1997, 1998, 1999

Key Specs

Petrol

1590 cm³
97 cu-in

Inline 4

107 PS
106 HP / 79 kW

144 Nm
106 lb-ft

Compare with another car

More pictures

Suzuki Escudo 1997 1600JM 5-Door Automatic Body, Model and Production details

Generation :	2nd Generation FT/GT

Body :	SUV / TT

Num. of Doors :	5 doors


Suzuki Escudo 1997 1600JM 5-Door Automatic Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	G16

Fuel type :	Petrol

Fuel System :	Multipoint Indirect Injection

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	1590 cm³ / 97 cu-in

Bore x Stroke :	75.0 x 90.0 mm 2.95 x 3.54 inches

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	9.5

Horsepower :	107 PS / 106 HP / 79 kW @ 6000 rpm

Maximum torque :	144 Nm / 106 lb-ft @ 4500 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	4 speed Automatic Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: Reverse Gear Ratio: 2.70 Final Drive Ratio: 5.13


Suzuki Escudo 1997 1600JM 5-Door Automatic Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	66 L 17.4 US gallons 14.5 UK gallons

Suzuki Escudo 1997 1600JM 5-Door Automatic Performance

Top Speed :	- km/h / - Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Suzuki Escudo 1997 1600JM 5-Door Automatic Size, Dimensions, Aerodynamics and Weight

Wheelbase :	248.0 cm / 97.64 inches

Length :	409.0 cm / 161.02 inches

Width :	169.5 cm / 66.73 inches

Height :	168.5 cm / 66.34 inches

Front Axle :	146.0 cm / 57.48 inches

Rear Axle :	146.0 cm / 57.48 inches

Aerodynamic drag coefficient - Cx :	0.50

Curb Weight :	1280 kg / 2822 lbs

Weight/Power Output Ratio :	12 kg/hp


Suzuki Escudo 1997 1600JM 5-Door Automatic Interior size, Dimensions

Num. of Seats :	5 seats

Front legroom :	105.2 cm / 41.42 inches

Rear seat legroom :	91.2 cm / 35.91 inches

Front shoulder room :	134.1 cm / 52.8 inches

Rear shoulder room :	133.6 cm / 52.6 inches

Front head room :	101.3 cm / 39.88 inches

Rear head room :	100.6 cm / 39.61 inches

Trunk / Boot capacity :	-


Suzuki Escudo 1997 1600JM 5-Door Automatic Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Drums (- mm / - inches)

Front Tyres - Rims dimensions :	195/80 R15

Rear Tyres - Rims dimensions :	195/80 R15

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	De-Dion axle. Coil Springs.

What engine is in Suzuki Escudo 1997 1600JM 5-Door Automatic?
The Suzuki Escudo 1997 1600JM 5-Door Automatic has a Inline 4, Petrol engine with 1590 cm³ / 97 cu-in capacity.

How many horsepower (hp) does a 1997 Suzuki Escudo 1997 1600JM 5-Door Automatic have?
The 1997 Suzuki Escudo 1997 1600JM 5-Door Automatic has 107 PS / 106 bhp / 79 kW.

How much does a Suzuki Escudo 1997 1600JM 5-Door Automatic weighs?
The Suzuki Escudo 1997 1600JM 5-Door Automatic weighs 1280 Kg / 2822 lbs.

Is Suzuki Escudo 1997 1600JM 5-Door Automatic All Wheel Drive (AWD)?
Yes, the Suzuki Escudo 1997 1600JM 5-Door Automatic is All Wheel Drive (AWD).
