Make

Ion Quad Coupé 2004 Versions

Saturn Ion Quad Coupé 2004 2.0i Turbo Red Line Specs

(2006 - 2007) - Technical Specifications for Years 2006, 2007

Petrol

1998 cm³
121.9 cu-in

Inline 4

208 PS
205 HP / 153 kW

271 Nm
199 lb-ft

Saturn Ion Quad Coupé 2004 2.0i Turbo Red Line Body, Model and Production details

Generation :	Ion - 2004 Facelift

Body :	Coupé

Num. of Doors :	4 doors


Saturn Ion Quad Coupé 2004 2.0i Turbo Red Line Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	GM Ecotec LSJ

Fuel type :	Petrol

Fuel System :	Multipoint Indirect Injection

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	1998 cm³ / 121.9 cu-in

Bore x Stroke :	86.0 x 86.0 mm 3.39 x 3.39 inches

Number of valves :	16 Valves

Aspiration :	Turbo

Compression Ratio :	9.5

Horsepower :	208 PS / 205 HP / 153 kW @ 5600 rpm

Maximum torque :	271 Nm / 199 lb-ft @ 4400 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	5 speed Manual Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio: Reverse Gear Ratio: 3.17 Final Drive Ratio: 4.05


Saturn Ion Quad Coupé 2004 2.0i Turbo Red Line Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - EPA Highway ( - 2008):	7.8 L/100 km 36 MPG UK 30 MPG US

Fuel Consumption - Economy - EPA City ( - 2008):	10.7 L/100 km 26 MPG UK 22 MPG US

Fuel Consumption - Economy - EPA Combined ( - 2008):	9.4 L/100 km 30 MPG UK 25 MPG US

Range (EPA):	521 km / 324 miles

Fuel Tank Capacity :	49 L 12.9 US gallons 10.8 UK gallons

Catalytic converter :	Yes, with Lamda-Sensor

Saturn Ion Quad Coupé 2004 2.0i Turbo Red Line Performance

Top Speed :	- km/h / - Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Saturn Ion Quad Coupé 2004 2.0i Turbo Red Line Size, Dimensions, Aerodynamics and Weight

Wheelbase :	262.1 cm / 103.19 inches

Length :	469.9 cm / 185 inches

Width :	172.5 cm / 67.91 inches

Height :	141.7 cm / 55.79 inches

Front Axle :	149.4 cm / 58.82 inches

Rear Axle :	148.3 cm / 58.39 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1336 kg / 2945 lbs

Weight/Power Output Ratio :	6.4 kg/hp


Saturn Ion Quad Coupé 2004 2.0i Turbo Red Line Interior size, Dimensions

Num. of Seats :	4 seats

Seat distribution :	2+2

Front legroom :	107.2 cm / 42.2 inches

Rear seat legroom :	83.1 cm / 32.72 inches

Front shoulder room :	137.2 cm / 54.02 inches

Rear shoulder room :	129.5 cm / 50.98 inches

Front head room :	98.8 cm / 38.9 inches

Rear head room :	92.7 cm / 36.5 inches

Front hip room :	125.5 cm / 49.41 inches

Rear hip room :	122.7 cm / 48.31 inches

Trunk / Boot capacity :	402 L / 14.2 cu-ft


Saturn Ion Quad Coupé 2004 2.0i Turbo Red Line Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (295 mm / 11.61 inches)

Rear Brakes - Disc dimensions :	Discs (269 mm / 10.59 inches)

Front Tyres - Rims dimensions :	215/45 R17

Rear Tyres - Rims dimensions :	215/45 R17

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	Semi-rigid axle. Coil Springs.
