Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Specs

(2024 - ) - Technical Specifications for Years 2024, 2025

Key Specs

Plug-in Hybrid / Petrol

2488 cm³
151.8 cu-in

Inline 4

233 PS
230 HP / 171 kW

Compare with another car

More pictures

Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Body, Model and Production details

Generation :	Transit Custom 2 - 2024 New Model

Body :	Van

Num. of Doors :	4 doors


Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Plug-in Hybrid / Petrol

Fuel System :	Injection

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	2488 cm³ / 151.8 cu-in

Bore x Stroke :	89.0 x 100.0 mm 3.5 x 3.94 inches

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	13.0

Horsepower :	118 PS / 116 HP / 87 kW @ 5500 rpm

Maximum torque :	205 Nm / 151 lb-ft @ 4500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	1 speed CVT


Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Electric Engines Technical Data

Total System Power :	233 PS / 230 HP / 171 kW

Total System Torque :	- Nm / - lb-ft

Total electric torque :	320 Nm / 236 lb-ft

Number of electric engines:	1

Electric engine type:	PSM - Permanent Magnet Synchronous Motor


Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	63 L 16.6 US gallons 13.9 UK gallons

Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Battery Technical Data, Charging and Range

Range (WLTP):	56 km / 35 miles

Battery type :	Lithium-ion

Battery capacity :	16.5 kWh

Net battery capacity :	11.8 kWh

Catalytic converter :	Y

Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Performance

Top Speed :	- km/h / - Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Size, Dimensions, Aerodynamics and Weight

Wheelbase :	350.0 cm / 137.8 inches

Length :	545.0 cm / 214.57 inches

Width :	199.9 cm / 78.7 inches

Width with mirrors :	227.5 cm / 89.57 inches

Height :	198.0 cm / 77.95 inches

Front Axle :	172.5 cm / 67.91 inches

Rear Axle :	171.6 cm / 67.56 inches

Cargo box inside length :	300.2 cm / 118.19 inches

Cargo box inside height :	142.5 cm / 56.1 inches

Max. width at wheelhouse :	139.2 cm / 54.8 inches

Loading height :	56.7 cm / 22.32 inches

Rear door width :	140.0 cm / 55.12 inches

Rear door height :	131.6 cm / 51.81 inches

Side door width :	103.0 cm / 40.55 inches

Side door height :	130.1 cm / 51.22 inches

Max. Towing Capacity Weight :	1850 kg / 4079 lbs

Aerodynamic drag coefficient - Cx :	-


Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Interior size, Dimensions

Num. of Seats :	3 seats

Trunk / Boot capacity :	6500 L / 229.5 cu-ft

Trunk / Boot First Row :	6800 L / 240.1 cu-ft


Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (308 mm / 12.13 inches)

Rear Brakes - Disc dimensions :	Vented Discs (304 mm / 11.97 inches)

Front Tyres - Rims dimensions :	215/65 R16

Rear Tyres - Rims dimensions :	215/65 R16

Front Suspension :	MacPherson struts. Coil springs. Anti-roll bar.

Rear Suspension :	Independent. Coil Springs. Anti-roll bar.

What engine is in Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto?
The Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto has a Inline 4, Hybrid / Petrol engine with 2488 cm³ / 151.8 cu-in capacity.
The Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto also have 1 electric engine(s) PSM - Permanent Magnet Synchronous Motor.

How many horsepower (hp) does a 2024 Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto have?
The 2024 Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto has 233 PS / 230 bhp / 171 kW.

Is Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto All Wheel Drive (AWD)?
No, the Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).

What is the Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto electric range?
The electric range of Ford Transit Custom Van L2 2024 320 2.5 Duratec PHEV Auto is 56 Km / 35 miles WLTP.
