Cupra Ateca 2.0 TSI 4Drive DSG Specs

(2018 - 2020) - Technical Specifications for Years 2018, 2019, 2020

Key Specs

Petrol

1984 cm³
121.1 cu-in

Inline 4

300 PS
296 HP / 221 kW

400 Nm
295 lb-ft

247 km/h
154 Mph

8.7 L/100 km
32 MPG UK
27 MPG US

Compare with another car

More pictures

Cupra Ateca 2.0 TSI 4Drive DSG Body, Model and Production details

Generation :	Ateca

Body :	SUV

Num. of Doors :	5 doors


Cupra Ateca 2.0 TSI 4Drive DSG Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	DNU

Fuel type :	Petrol

Fuel System :	Direct Injection

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	1984 cm³ / 121.1 cu-in

Bore x Stroke :	82.5 x 92.8 mm 3.25 x 3.65 inches

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	9.3

Horsepower :	300 PS / 296 HP / 221 kW @ 5300-6500 rpm

Maximum torque :	400 Nm / 295 lb-ft @ 2000-5200 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	7 speed Dualclutch Automatic


Cupra Ateca 2.0 TSI 4Drive DSG Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	9.6 L/100 km 29 MPG UK 25 MPG US

Fuel Consumption - Economy - Open road NEDC :	6.6 L/100 km 43 MPG UK 36 MPG US

Fuel Consumption - Economy - Combined NEDC :	7.7 L/100 km 37 MPG UK 31 MPG US

Fuel Consumption - Economy - Low WLTP:	11.3 L/100 km 25 MPG UK 21 MPG US

Fuel Consumption - Economy - Medium WLTP:	8.6 L/100 km 33 MPG UK 27 MPG US

Fuel Consumption - Economy - High WLTP:	7.6 L/100 km 37 MPG UK 31 MPG US

Fuel Consumption - Economy - Extra high WLTP:	8.7 L/100 km 32 MPG UK 27 MPG US

Fuel Consumption - Economy - Combined WLTP:	8.7 L/100 km 32 MPG UK 27 MPG US

Range :	714 km / 444 miles

Range (WLTP):	632 km / 393 miles

Fuel Tank Capacity :	55 L 14.5 US gallons 12.1 UK gallons

CO2 emissions :	175 g/km (Cupra)

CO2 emissions WLTP :	197 g/km (Cupra)

Emission standard :	Euro 6d - WLTP

Catalytic converter :	Particle Filter

Cupra Ateca 2.0 TSI 4Drive DSG Performance

Top Speed :	247 km/h / 154 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	5.2 s


Cupra Ateca 2.0 TSI 4Drive DSG Size, Dimensions, Aerodynamics and Weight

Wheelbase :	263.1 cm / 103.58 inches

Length :	437.6 cm / 172.28 inches

Width :	184.1 cm / 72.48 inches

Width with mirrors :	207.8 cm / 81.81 inches

Height :	161.1 cm / 63.43 inches

Front Axle :	157.5 cm / 62.01 inches

Rear Axle :	154.9 cm / 60.98 inches

Max. Towing Capacity Weight :	2100 kg / 4630 lbs

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1626 kg / 3585 lbs

Weight/Power Output Ratio :	5.4 kg/hp


Cupra Ateca 2.0 TSI 4Drive DSG Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	485 L / 17.1 cu-ft

Trunk / Boot First Row :	1579 L / 55.8 cu-ft


Cupra Ateca 2.0 TSI 4Drive DSG Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (340 mm / 13.39 inches)

Rear Brakes - Disc dimensions :	Vented Discs (310 mm / 12.2 inches)

Front Tyres - Rims dimensions :	245/35 R20

Rear Tyres - Rims dimensions :	245/35 R20

Front Wheels Width :	8"

Rear Wheels Width :	8"

Turning circle :	10.8 m / 35.4 feet

Front Suspension :	Independent. MacPherson. Coil Springs.

Rear Suspension :	Multi-link. Coil Springs.

What engine is in Cupra Ateca 2.0 TSI 4Drive DSG?
The Cupra Ateca 2.0 TSI 4Drive DSG has a Inline 4, Petrol engine with 1984 cm³ / 121.1 cu-in capacity.

How many horsepower (hp) does a 2018 Cupra Ateca 2.0 TSI 4Drive DSG have?
The 2018 Cupra Ateca 2.0 TSI 4Drive DSG has 300 PS / 296 bhp / 221 kW.

How much does a Cupra Ateca 2.0 TSI 4Drive DSG weighs?
The Cupra Ateca 2.0 TSI 4Drive DSG weighs 1626 Kg / 3585 lbs.

What is the top speed of a Cupra Ateca 2.0 TSI 4Drive DSG?
The Cupra Ateca 2.0 TSI 4Drive DSG top speed is 247 Km/h / 154 mph.

Is Cupra Ateca 2.0 TSI 4Drive DSG All Wheel Drive (AWD)?
Yes, the Cupra Ateca 2.0 TSI 4Drive DSG is All Wheel Drive (AWD).

How fast is a Cupra Ateca 2.0 TSI 4Drive DSG?
The Cupra Ateca 2.0 TSI 4Drive DSG can reach 0 to 100 km/h (0 to 62 mph) in 5.2 seconds and has a top speed of 247 km/h.
