ProAce 2024 Van L1 Versions

- 1.5 D-4D (2024)- 2.0 D-4D (2024)- 2.0 D-4D Auto (2024)- Electric 50kWh (2024)

Toyota ProAce 2024 Van L1 1.5 D-4D Specs

(2024 - ) - Technical Specifications for Years 2024, 2025

Key Specs

Diesel

1499 cm³
91.5 cu-in

Inline 4

120 PS
118 HP / 88 kW

300 Nm
221 lb-ft

160 km/h
99 Mph

6.6 L/100 km
43 MPG UK
36 MPG US

Compare with another car

More pictures

Toyota ProAce 2024 Van L1 1.5 D-4D Body, Model and Production details

Generation :	ProAce II - 2024 Facelift

Body :	Van

Num. of Doors :	4 doors


Toyota ProAce 2024 Van L1 1.5 D-4D Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	PSA BlueHDI YH01 DV5

Fuel type :	Diesel

Fuel System :	Common Rail

Lubrication :	See oil information Toyota ProAce 2024 Van L1 1.5 D-4D Oil Specifications - Engine oil All Weather: 0W20 OEM: PSA B71 2010 API/ACEA: ACEA C6 Engine oil capacity (with filter): 4.0 L

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	1499 cm³ / 91.5 cu-in

Bore x Stroke :	75 x 84.8 mm 2.95 x 3.34 inches

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	16.5

Horsepower :	120 PS / 118 HP / 88 kW @ 3500 rpm

Maximum torque :	300 Nm / 221 lb-ft @ 1750 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual


Toyota ProAce 2024 Van L1 1.5 D-4D Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Low WLTP:	7.4 L/100 km 38 MPG UK 32 MPG US

Fuel Consumption - Economy - Medium WLTP:	5.9 L/100 km 48 MPG UK 40 MPG US

Fuel Consumption - Economy - High WLTP:	5.7 L/100 km 50 MPG UK 41 MPG US

Fuel Consumption - Economy - Extra high WLTP:	7.5 L/100 km 38 MPG UK 31 MPG US

Fuel Consumption - Economy - Combined WLTP:	6.6 L/100 km 43 MPG UK 36 MPG US

Range (WLTP):	1045 km / 649 miles

Fuel Tank Capacity :	69 L 18.2 US gallons 15.2 UK gallons

AdBlue Tank :	22 L 5.8 US gallons 4.8 UK gallons

CO2 emissions WLTP :	173 g/km (Toyota)

Catalytic converter :	Particle Filter (with SCR cat.)

Toyota ProAce 2024 Van L1 1.5 D-4D Performance

Top Speed :	160 km/h / 99 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Toyota ProAce 2024 Van L1 1.5 D-4D Size, Dimensions, Aerodynamics and Weight

Wheelbase :	327.5 cm / 128.94 inches

Length :	498.1 cm / 196.1 inches

Width :	192.4 cm / 75.75 inches

Width with mirrors :	220.4 cm / 86.77 inches

Height :	191.0 cm / 75.2 inches

Front Axle :	163.0 cm / 64.17 inches

Rear Axle :	161.8 cm / 63.7 inches

Ground clearance :	15.0 cm / 5.91 inches

Cargo box inside length :	251.2 cm / 98.9 inches

Cargo box inside height :	133.7 cm / 52.64 inches

Cargo width :	163.6 cm / 64.41 inches

Max. Towing Capacity Weight :	1800 kg / 3968 lbs

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1656 kg / 3651 lbs

Weight/Power Output Ratio :	13.8 kg/hp


Toyota ProAce 2024 Van L1 1.5 D-4D Interior size, Dimensions

Num. of Seats :	3 seats

Trunk / Boot capacity :	5300 L / 187.2 cu-ft

Trunk / Boot First Row :	5300 L / 187.2 cu-ft


Toyota ProAce 2024 Van L1 1.5 D-4D Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Discs (- mm / - inches)

Front Tyres - Rims dimensions :	215/65 R16

Rear Tyres - Rims dimensions :	215/65 R16

Turning circle :	12.4 m / 40.7 feet

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	Trailing arm. Coil Springs.

What engine is in Toyota ProAce 2024 Van L1 1.5 D-4D?
The Toyota ProAce 2024 Van L1 1.5 D-4D has a Inline 4, Diesel engine with 1499 cm³ / 91.5 cu-in capacity.

How many horsepower (hp) does a 2024 Toyota ProAce 2024 Van L1 1.5 D-4D have?
The 2024 Toyota ProAce 2024 Van L1 1.5 D-4D has 120 PS / 118 bhp / 88 kW.

How much does a Toyota ProAce 2024 Van L1 1.5 D-4D weighs?
The Toyota ProAce 2024 Van L1 1.5 D-4D weighs 1656 Kg / 3651 lbs.

What is the top speed of a Toyota ProAce 2024 Van L1 1.5 D-4D?
The Toyota ProAce 2024 Van L1 1.5 D-4D top speed is 160 Km/h / 99 mph.

Is Toyota ProAce 2024 Van L1 1.5 D-4D All Wheel Drive (AWD)?
No, the Toyota ProAce 2024 Van L1 1.5 D-4D is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
