Make

Model 3 2023 Versions

Tesla Model 3 2023 Performance 82 kWh AWD Specs

(2023 - ) - Technical Specifications for Years 2023, 2024, 2025

Electric

510 PS
503 HP / 375 kW

741 Nm
546 lb-ft

262 km/h
163 Mph

528 km
328 miles

476 km
296 miles

Tesla Model 3 2023 Performance 82 kWh AWD Body, Model and Production details

Generation :	Model 3 - 2023 Facelift

Body :	Fastback

Num. of Doors :	5 doors


Tesla Model 3 2023 Performance 82 kWh AWD Engine Technical Data

Engine Type :	Electric

Total electric power :	510 PS / 503 HP / 375 kW

Total electric torque :	741 Nm / 546 lb-ft

Horsepower :	510 PS / 503 HP / 375 kW

Maximum torque :	741 Nm / 546 lb-ft

Number of electric engines:	2

Electric engine 1 type:	PSM - Permanent Magnet Synchronous Motor

Rear Axle Electric Engine Power:	412 PS / 406 HP / 303 kW

Electric engine 2 type:	ASM - Asynchronous Motor

Front Axle Electric Engine Power:	215 PS / 212 HP / 158 kW

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	1 speed Reduction Gear

Range (EPA):

476 km / 296 miles

Range (WLTP):

528 km / 328 miles

Average energy consumption WLTP:

14 kWh / 100 km (4.44 miles / kWh)

Battery type :

Lithium-ion

Battery voltage :

355 V

Fast charge current :

250.0 kW

Battery capacity :

82.0 kWh

Net battery capacity :

77.0 kWh

CO2 emissions WLTP :

0 g/km (Tesla)

Tesla Model 3 2023 Performance 82 kWh AWD Performance

Top Speed :	262 km/h / 163 Mph

Acceleration 0 to 60 mph (0 to 96 Km/h) :	2.9 s

Acceleration 0 to 100 km/h (0 to 62 mph) :	3.1 s


Tesla Model 3 2023 Performance 82 kWh AWD Size, Dimensions, Aerodynamics and Weight

Wheelbase :	287.5 cm / 113.19 inches

Length :	472.0 cm / 185.83 inches

Width :	185.0 cm / 72.83 inches

Width with mirrors :	208.9 cm / 82.24 inches

Height :	143.1 cm / 56.34 inches

Front Axle :	158.4 cm / 62.36 inches

Rear Axle :	157.0 cm / 61.81 inches

Ground clearance :	12.8 cm / 5.04 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1919 kg / 4231 lbs

Weight/Power Output Ratio :	3.8 kg/hp


Tesla Model 3 2023 Performance 82 kWh AWD Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	594 L / 21 cu-ft


Tesla Model 3 2023 Performance 82 kWh AWD Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Front Tyres - Rims dimensions :	235/35 R20

Rear Tyres - Rims dimensions :	235/35 R20

Turning circle :	11.7 m / 38.4 feet

Front Suspension :	Double wishbone. Coil Springs.

Rear Suspension :	Multi-link. Coil Springs.
