Make

H247 GLA 2023 Versions

Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Specs

(2025 - ) - Technical Specifications for 2025
Mercedes Benz H247 GLA 2023 image

Key Specs

Diesel
1950 cm3
119 cu-in
Inline 4
190 PS
187 HP / 140 kW
400 Nm
295 lb-ft
218 km/h
135 Mph
5.7 L/100 km
50 MPG UK
41 MPG US

Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Body, Model and Production details Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Body, Model and Production details

Generation : H 247 GLA - 2023 Facelift
Body : SUV
Num. of Doors : 5 doors

Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Engine Technical Data Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Engine Technical Data

Engine type - Number of cylinders : Inline 4
Engine Code : OM654.920
Fuel type : Diesel
Fuel System : Common Rail
Lubrication :
Engine Alignment : Transverse
Engine Position : Front
Engine displacement : 1950 cm3 / 119 cu-in
Bore x Stroke : 82.0 x 92.3 mm
3.23 x 3.63 inches
Number of valves : 16 Valves
Aspiration : Turbo Intercooler
Compression Ratio : 15.5
Horsepower : 190 PS / 187 HP / 140 kW
@ 3800 rpm
Maximum torque : 400 Nm / 295 lb-ft
@ 1600-2600 rpm
Drive wheels - Traction - Drivetrain : AWD
Transmission Gearbox - Number of speeds :

Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Fuel Consumption (Economy), Emissions and Range Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Low WLTP: 7.4 L/100 km
38 MPG UK
32 MPG US
Fuel Consumption - Economy - Medium WLTP: 5.8 L/100 km
49 MPG UK
41 MPG US
Fuel Consumption - Economy - High WLTP: 4.9 L/100 km
58 MPG UK
48 MPG US
Fuel Consumption - Economy - Extra high WLTP: 5.7 L/100 km
50 MPG UK
41 MPG US
Fuel Consumption - Economy - Combined WLTP: 5.7 L/100 km
50 MPG UK
41 MPG US
Range (WLTP): 894 km / 556 miles
Fuel Tank Capacity : 51 L
13.5 US gallons
11.2 UK gallons
AdBlue Tank : 23 L
6.1 US gallons
5.1 UK gallons
CO2 emissions WLTP : 150 g/km (Mercedes Benz)
Emission standard : Euro 6E
Catalytic converter : Particle Filter (with SCR cat.)

Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Performance Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Performance

Top Speed : 218 km/h / 135 Mph
Acceleration 0 to 100 km/h (0 to 62 mph) : 7.6 s

Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Size, Dimensions, Aerodynamics and Weight Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Size, Dimensions, Aerodynamics and Weight

Wheelbase : 272.9 cm / 107.44 inches
Length : 441.2 cm / 173.7 inches
Width : 183.4 cm / 72.2 inches
Width with mirrors : 202.0 cm / 79.53 inches
Height : 161.6 cm / 63.62 inches
Front Axle : 160.5 cm / 63.19 inches
Rear Axle : 160.6 cm / 63.23 inches
Ground clearance : 14.3 cm / 5.63 inches
Approach angle (deg) : 18.3°
Breakover (Rampover) angle (deg) : 14.4°
Departure angle (deg) : 22.1°
Max. Towing Capacity Weight : 2000 kg / 4409 lbs
Aerodynamic drag coefficient - Cx : -
Curb Weight : 1725 kg / 3803 lbs
Weight/Power Output Ratio : 9.1 kg/hp

Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Interior size, Dimensions Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Interior size, Dimensions

Num. of Seats : 5 seats
Trunk / Boot capacity : 427 L / 15.1 cu-ft
Trunk / Boot First Row : 1422 L / 50.2 cu-ft

Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Brakes, Tires, Steering and Suspension Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions : Vented Discs
(- mm / - inches)
Rear Brakes - Disc dimensions : Discs
(- mm / - inches)
Front Tyres - Rims dimensions : 215/65 R17
Rear Tyres - Rims dimensions : 215/65 R17
Turning circle : 11.4 m / 37.4 feet
Front Suspension : Independent. MacPherson. Coil Springs. Anti-roll bar.
Rear Suspension : Multi-link. Coil Springs. Anti-roll bar.
If you found an error in these specifications submit your correction here
What engine is in Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT?
The Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT has a Inline 4, Diesel engine with 1950 cm3 / 119 cu-in capacity.

How many horsepower (hp) does a 2025 Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT have?
The 2025 Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT has 190 PS / 187 bhp / 140 kW.

How much does a Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT weighs?
The Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT weighs 1725 Kg / 3803 lbs.

What is the top speed of a Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT?
The Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT top speed is 218 Km/h / 135 mph.

Is Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT All Wheel Drive (AWD)?
Yes, the Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT is All Wheel Drive (AWD).

How fast is a Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT?
The Mercedes Benz H247 GLA 2023 220 d 4MATIC 8G-DCT can reach 0 to 100 km/h (0 to 62 mph) in 7.6 seconds and has a top speed of 218 km/h.
