Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Specs

(2023 - 2024) - Technical Specifications for Years 2023, 2024

Key Specs

Plug-in Hybrid / Petrol

2999 cm³
183 cu-in

Inline 6

510 PS
503 HP / 375 kW

750 Nm
553 lb-ft

250 km/h
155 Mph

0.8 L/100 km
353 MPG UK
294 MPG US

Compare with another car

More pictures

Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Body, Model and Production details

Generation :	W223

Body :	Sedan

Num. of Doors :	4 doors


Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Engine Technical Data

Engine type - Number of cylinders :	Inline 6

Engine Code :	M 256.930

Fuel type :	Plug-in Hybrid / Petrol

Fuel System :	Direct Injection

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	2999 cm³ / 183 cu-in

Bore x Stroke :	83.0 x 92.4 mm 3.27 x 3.64 inches

Number of valves :	24 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	10.5

Horsepower :	367 PS / 362 HP / 270 kW @ 5500-6100 rpm

Maximum torque :	500 Nm / 368 lb-ft @ 1600-4500 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	9 speed Automatic


Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Electric Engines Technical Data

Total System Power :	510 PS / 503 HP / 375 kW

Total System Torque :	750 Nm / 553 lb-ft

Total electric power :	150 PS / 148 HP / 110 kW

Total electric torque :	440 Nm / 324 lb-ft

Number of electric engines:	1

Transmission Electric Engine Power:	150 PS / 148 HP / 110 kW

Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined WLTP:

0.8 L/100 km
353 MPG UK
294 MPG US

Fuel Tank Capacity :

67 L
17.7 US gallons
14.7 UK gallons

Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Battery Technical Data, Charging and Range

Range (WLTP):

99 km / 62 miles

Battery type :

Lithium-ion

Charging Time
DC	60 kW	80%	0h20m
Wallbox 3-phase	11 kW	100%	2h07m

Fast charge current :

60.0 kW

Battery capacity :

28.6 kWh

Net battery capacity :

21.5 kWh

CO2 emissions WLTP :

18 g/km (Mercedes Benz)

Emission standard :

Euro 6d - WLTP

Catalytic converter :

Particle Filter

Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Performance

Top Speed :	250 km/h / 155 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	5.1 s


Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Size, Dimensions, Aerodynamics and Weight

Wheelbase :	339.6 cm / 133.7 inches

Length :	546.9 cm / 215.31 inches

Width :	195.4 cm / 76.93 inches

Width with mirrors :	210.9 cm / 83.03 inches

Height :	151.0 cm / 59.45 inches

Front Axle :	165.5 cm / 65.16 inches

Rear Axle :	168.3 cm / 66.26 inches

Ground clearance :	13.0 cm / 5.12 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2650 kg / 5842 lbs

Weight/Power Output Ratio :	5.2 kg/hp


Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	325 L / 11.5 cu-ft


Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Front Tyres - Rims dimensions :	255/45 R19

Rear Tyres - Rims dimensions :	255/45 R19

Front Wheels Width :	8.5"

Rear Wheels Width :	8.5"

Turning circle :	13.4 m / 44 feet

Front Suspension :	Multi-link. Pneumatic-Air

Rear Suspension :	Multi-link. Pneumatic-Air

What engine is in Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC?
The Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC has a Inline 6, Hybrid / Petrol engine with 2999 cm³ / 183 cu-in capacity.
The Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC also have 1 electric engine(s) .

How many horsepower (hp) does a 2023 Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC have?
The 2023 Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC has 510 PS / 503 bhp / 375 kW.

How much does a Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC weighs?
The Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC weighs 2650 Kg / 5842 lbs.

What is the top speed of a Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC?
The Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC top speed is 250 Km/h / 155 mph.

Is Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC All Wheel Drive (AWD)?
Yes, the Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC is All Wheel Drive (AWD).

What is the Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC electric range?
The electric range of Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC is 99 Km / 62 miles WLTP.

How fast is a Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC?
The Mercedes Benz Z223 Maybach S 580 e 4MATIC 9G-TRONIC can reach 0 to 100 km/h (0 to 62 mph) in 5.1 seconds and has a top speed of 250 km/h.
