Make

323 VI Versions

Mazda 323 VI 1.6 Specs

(2001 - 2003) - Technical Specifications for Years 2001, 2002, 2003

Petrol

1598 cm³
97.5 cu-in

Inline 4

100 PS
99 HP / 74 kW

145 Nm
106 lb-ft

182 km/h
113 Mph

7.5 L/100 km
38 MPG UK
31 MPG US

Mazda 323 VI 1.6 Body, Model and Production details

Body :	-

Num. of Doors :	5 doors


Mazda 323 VI 1.6 Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	ZM

Fuel type :	Petrol

Fuel System :	MPI - Mazda EGI

Engine Alignment :	Transverse

Engine displacement :	1598 cm³ / 97.5 cu-in

Bore x Stroke :	78.0 x 83.6 mm 3.07 x 3.29 inches

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	9.7

Horsepower :	100 PS / 99 HP / 74 kW @ 5500 rpm

Maximum torque :	145 Nm / 106 lb-ft @ 3700 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	5 speed Manual


Mazda 323 VI 1.6 Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	7.5 L/100 km 38 MPG UK 31 MPG US

Fuel Consumption - Economy - Open road:	6.3 L/100 km 45 MPG UK 37 MPG US

Fuel Consumption - Economy - City:	9.6 L/100 km 29 MPG UK 25 MPG US

Range :	733 km / 456 miles

Fuel Tank Capacity :	55 L 14.5 US gallons 12.1 UK gallons


Mazda 323 VI 1.6 Size, Dimensions, Aerodynamics and Weight

Wheelbase :	261.0 cm / 102.76 inches

Length :	425.0 cm / 167.32 inches

Width :	170.0 cm / 66.93 inches

Height :	142.0 cm / 55.91 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1085 kg / 2392 lbs

Weight/Power Output Ratio :	10.9 kg/hp


Mazda 323 VI 1.6 Interior size, Dimensions

Trunk / Boot capacity :	356 L / 12.6 cu-ft


Mazda 323 VI 1.6 Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (258 mm / 10.16 inches)

Rear Brakes - Disc dimensions :	Discs (261 mm / 10.28 inches)

Front Tyres - Rims dimensions :	185/65 R14

Rear Tyres - Rims dimensions :	185/65 R14

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	Multi-link. Coil Springs. Anti-roll bar
