Generation : | CX-5 2nd Gen. (KF) - 2017 New Model |
Body : | SUV / TT |
Num. of Doors : | 5 doors |
![]() |
|
Engine type - Number of cylinders : | Inline 4 |
Engine Code : | - |
Fuel type : | Petrol |
Fuel System : | Direct Injection |
Engine Alignment : | Transverse |
Engine Position : | Front |
Engine displacement : | 1998 cm3 / 121.9 cu-in |
Bore x Stroke : |
83.5 x 91.2 mm 3.29 x 3.59 inches |
Number of valves : | 16 Valves |
Aspiration : | naturally-aspirated |
Compression Ratio : | 13.0 |
Horsepower : |
165 PS / 163 HP / 121 kW @ 6000 rpm |
Maximum torque : |
213 Nm / 157 lb-ft @ 4000 rpm |
Drive wheels - Traction - Drivetrain : | FWD |
Transmission Gearbox - Number of speeds : |
6 speed Automatic
|
![]() |
|
Fuel Consumption - Economy - City NEDC : |
7.8 L/100 km 36 MPG UK 30 MPG US |
Fuel Consumption - Economy - Open road NEDC : |
5.9 L/100 km 48 MPG UK 40 MPG US |
Fuel Consumption - Economy - Combined NEDC : |
6.6 L/100 km 43 MPG UK 36 MPG US |
Fuel Consumption - Economy - Combined WLTP: |
7.3 L/100 km 39 MPG UK 32 MPG US |
Range : | 848 km / 527 miles |
Range (WLTP): | 767 km / 477 miles |
Fuel Tank Capacity : |
56 L 14.8 US gallons 12.3 UK gallons |
CO2 emissions : | 150 g/km (Mazda) |
CO2 emissions WLTP : | 165 g/km (Mazda) |
Catalytic converter : | Y |
![]() |
|
Top Speed : | 192 km/h / 119 Mph |
Acceleration 0 to 100 km/h (0 to 62 mph) : | 9.8 s |
![]() |
|
Wheelbase : | 270.0 cm / 106.3 inches |
Length : | 455.0 cm / 179.13 inches |
Width : | 184.0 cm / 72.44 inches |
Height : | 167.5 cm / 65.94 inches |
Front Axle : | 159.5 cm / 62.8 inches |
Rear Axle : | 159.5 cm / 62.8 inches |
Ground clearance : | 19.2 cm / 7.56 inches |
Max. Towing Capacity Weight : | 2000 kg / 4409 lbs |
Aerodynamic drag coefficient - Cx : | - |
Curb Weight : | 1570 kg / 3461 lbs |
Dry Weight : | 1459 kg / 3217 lbs |
Weight/Power Output Ratio : | 9.5 kg/hp |
![]() |
|
Num. of Seats : | 5 seats |
Trunk / Boot capacity : | from 477 L / 16.8 cu-ft |
![]() |
|||
Front Brakes - Disc dimensions : |
Vented Discs (297 mm / 11.69 inches) |
||
Rear Brakes - Disc dimensions : |
Discs (303 mm / 11.93 inches) |
||
Front Tyres - Rims dimensions : | 225/65 R17 | ||
Rear Tyres - Rims dimensions : | 225/65 R17 | ||
Turning circle : | 11.0 m / 36.1 feet | ||
Front Suspension : | Independent. MacPherson. Coil Springs. Anti-roll bar. | ||
Rear Suspension : | Multi-link. Coil Springs. Anti-roll bar. |
