Browse Car Specifications...

RX (AL30) Versions

Lexus RX (AL30) 450h+ Plug-in Hybrid AWD e-CVT Specs

(2023 - ) - Technical Specifications for Years 2023, 2024, 2025

Plug-in Hybrid / Petrol

2487 cm³
151.8 cu-in

Inline 4

309 PS
305 HP / 227 kW

200 km/h
124 Mph

1.1 L/100 km
257 MPG UK
214 MPG US

Lexus RX (AL30) 450h+ Plug-in Hybrid AWD e-CVT Body, Model and Production details

Generation :	RX 5th Gen. (AL30) - 2022 New Model

Body :	SUV

Num. of Doors :	5 doors


Lexus RX (AL30) 450h+ Plug-in Hybrid AWD e-CVT Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	A25A-FXS

Fuel type :	Plug-in Hybrid / Petrol

Fuel System :	Direct Injection

Lubrication :	See oil information Lexus RX (AL30) 450h+ Plug-in Hybrid AWD e-CVT Oil Specifications - Engine oil All Weather: 0W16 API/ACEA: API SN/RC Engine oil capacity (with filter): 4.5 L

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	2487 cm³ / 151.8 cu-in

Bore x Stroke :	87.5 x 103.4 mm 3.44 x 4.07 inches

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	14.0

Horsepower :	185 PS / 182 HP / 136 kW @ 6000 rpm

Maximum torque :	227 Nm / 167 lb-ft @ 3200-3700 rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	1 speed CVT


Lexus RX (AL30) 450h+ Plug-in Hybrid AWD e-CVT Electric Engines Technical Data

Total System Power :	309 PS / 305 HP / 227 kW

Total System Torque :	- Nm / - lb-ft

Total electric power :	236 PS / 233 HP / 174 kW

Total electric torque :	391 Nm / 288 lb-ft

Number of electric engines:	2

Electric engine type:	PSM - Permanent Magnet Synchronous Motor

Transmission Electric Engine Power:	182 PS / 180 HP / 134 kW

Electric engine 2 type:	PSM - Permanent Magnet Synchronous Motor

Rear Axle Electric Engine Power:	54 PS / 53 HP / 40 kW

Fuel Consumption - Economy - Combined WLTP:

1.1 L/100 km
257 MPG UK
214 MPG US

Fuel Tank Capacity :

55 L
14.5 US gallons
12.1 UK gallons

Range (WLTP):

68 km / 42 miles

Average energy consumption WLTP:

17.9 kWh / 100 km (3.47 miles / kWh)

Battery type :

Lithium-ion

Charging Time
Wallbox 1-phase	6.6 kW	100%	2h15m

Battery capacity :

18.1 kWh

CO2 emissions WLTP :

25 g/km (Lexus)

Emission standard :

Euro 6e

Catalytic converter :

Particle Filter

Lexus RX (AL30) 450h+ Plug-in Hybrid AWD e-CVT Performance

Top Speed :	200 km/h / 124 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	6.5 s


Lexus RX (AL30) 450h+ Plug-in Hybrid AWD e-CVT Size, Dimensions, Aerodynamics and Weight

Wheelbase :	285.0 cm / 112.2 inches

Length :	489.0 cm / 192.52 inches

Width :	192.0 cm / 75.59 inches

Width with mirrors :	221.0 cm / 87.01 inches

Height :	169.5 cm / 66.73 inches

Front Axle :	165.5 cm / 65.16 inches

Rear Axle :	169.5 cm / 66.73 inches

Ground clearance :	18.2 cm / 7.17 inches

Approach angle (deg) :	15.0°

Departure angle (deg) :	24.0°

Max. Towing Capacity Weight :	2000 kg / 4409 lbs

Aerodynamic drag coefficient - Cx :	0.35

Curb Weight :	2185 kg / 4817 lbs

Weight/Power Output Ratio :	7.1 kg/hp


Lexus RX (AL30) 450h+ Plug-in Hybrid AWD e-CVT Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	461 L / 16.3 cu-ft

Trunk / Boot First Row :	1678 L / 59.3 cu-ft


Lexus RX (AL30) 450h+ Plug-in Hybrid AWD e-CVT Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Front Tyres - Rims dimensions :	235/60 R19

Rear Tyres - Rims dimensions :	235/60 R19

Turning circle :	12.6 m / 41.3 feet

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	Multi-link. Coil Springs. Anti-roll bar.
