Jaguar F-Type Convertible Project 7 Specs

(2014 - 2015) - Technical Specifications for Years 2014, 2015

Petrol

5000 cm³
305.1 cu-in

V 8

575 PS
567 HP / 423 kW

680 Nm
501 lb-ft

300 km/h
186 Mph

Jaguar F-Type Convertible Project 7 Body, Model and Production details

Generation :	F Type X152

Body :	Cabrio

Num. of Doors :	2 doors


Jaguar F-Type Convertible Project 7 Engine Technical Data

Engine type - Number of cylinders :	V 8

Engine Code :	-

Fuel type :	Petrol

Fuel System :	Direct Injection.

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	5000 cm³ / 305.1 cu-in

Bore x Stroke :	92.5 x 93.0 mm 3.64 x 3.66 inches

Number of valves :	32 Valves

Aspiration :	Compressor + Intercooler

Compression Ratio :	9.5

Horsepower :	575 PS / 567 HP / 423 kW @ 6500 rpm

Maximum torque :	680 Nm / 501 lb-ft @ 2500-5500 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	8 speed Automatic

Clutch Type :	Torque Converter


Jaguar F-Type Convertible Project 7 Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	72 L 19 US gallons 15.8 UK gallons

CO2 emissions :	259 g/km (Jaguar)

Jaguar F-Type Convertible Project 7 Performance

Top Speed :	300 km/h / 186 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	3.9 s


Jaguar F-Type Convertible Project 7 Size, Dimensions, Aerodynamics and Weight

Wheelbase :	262.2 cm / 103.23 inches

Length :	451.9 cm / 177.91 inches

Width :	192.3 cm / 75.71 inches

Height :	127.7 cm / 50.28 inches

Front Axle :	158.5 cm / 62.4 inches

Rear Axle :	162.7 cm / 64.06 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1585 kg / 3494 lbs

Weight/Power Output Ratio :	2.8 kg/hp


Jaguar F-Type Convertible Project 7 Interior size, Dimensions

Num. of Seats :	2 seats

Seat distribution :	2

Trunk / Boot capacity :	196 L / 6.9 cu-ft


Jaguar F-Type Convertible Project 7 Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	- (398 mm / 15.67 inches)

Rear Brakes - Disc dimensions :	- (380 mm / 14.96 inches)

Front Tyres - Rims dimensions :	255/35 R20

Rear Tyres - Rims dimensions :	295/30 R20

Front Wheels Width :	9.0"

Rear Wheels Width :	10.5"

Steering :	Rack and pinion Hydraulic

Front Suspension :	Coil springs.

Rear Suspension :	Coil Springs.
