Make

Matrix 2001 Versions

- 1.5 CRDi (2001)- 1.6 GLS (2001)- 1.6 GLS Auto (2001)- 1.8 GLS (2001)- 1.8 GLS Auto (2001)

Hyundai Matrix 2001 1.6 GLS Specs

(2001 - 2005) - Technical Specifications for Years 2001, 2002, 2003, 2004, 2005

Key Specs

Petrol

1599 cm³
97.6 cu-in

Inline 4

103 PS
102 HP / 76 kW

141 Nm
103 lb-ft

170 km/h
106 Mph

7.8 L/100 km
36 MPG UK
30 MPG US

Compare with another car

More pictures

Hyundai Matrix 2001 1.6 GLS Body, Model and Production details

Generation :	Matrix - 2002 New Model

Body :	MPV

Num. of Doors :	5 doors


Hyundai Matrix 2001 1.6 GLS Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	G4ED

Fuel type :	Petrol

Fuel System :	Injection

Lubrication :	See oil information Hyundai Matrix 2001 1.6 GLS Oil Specifications - Engine oil All Weather: 10W40 API/ACEA: API SH Engine oil capacity (with filter): 3.3 L

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	1599 cm³ / 97.6 cu-in

Bore x Stroke :	76.5 x 87 mm 3.01 x 3.43 inches

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	10

Horsepower :	103 PS / 102 HP / 76 kW @ 5800 rpm

Maximum torque :	141 Nm / 103 lb-ft @ 4500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	5 speed Manual Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio:

Clutch Type :	Dry single disc clutch


Hyundai Matrix 2001 1.6 GLS Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	7.8 L/100 km 36 MPG UK 30 MPG US

Fuel Consumption - Economy - Open road:	6.6 L/100 km 43 MPG UK 36 MPG US

Fuel Consumption - Economy - City:	10.3 L/100 km 27 MPG UK 23 MPG US

Fuel Consumption - Economy - City NEDC :	9.1 L/100 km 31 MPG UK 26 MPG US

Fuel Consumption - Economy - Open road NEDC :	6.3 L/100 km 45 MPG UK 37 MPG US

Fuel Consumption - Economy - Combined NEDC :	7.3 L/100 km 39 MPG UK 32 MPG US

Range :	753 km / 468 miles

Fuel Tank Capacity :	55 L 14.5 US gallons 12.1 UK gallons

CO2 emissions :	174 g/km (Hyundai)

Emission standard :	Euro 4

Catalytic converter :	Y

Hyundai Matrix 2001 1.6 GLS Performance

Top Speed :	170 km/h / 106 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	12.7 s


Hyundai Matrix 2001 1.6 GLS Size, Dimensions, Aerodynamics and Weight

Wheelbase :	260.0 cm / 102.36 inches

Length :	402.5 cm / 158.46 inches

Width :	174.0 cm / 68.5 inches

Width with mirrors :	196.5 cm / 77.36 inches

Height :	163.5 cm / 64.37 inches

Front Axle :	148.5 cm / 58.46 inches

Rear Axle :	148.5 cm / 58.46 inches

Max. Towing Capacity Weight :	1300 kg / 2866 lbs

Aerodynamic drag coefficient - Cx :	0.33

Curb Weight :	1323 kg / 2917 lbs

Weight/Power Output Ratio :	12.8 kg/hp


Hyundai Matrix 2001 1.6 GLS Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	354 L / 12.5 cu-ft

Trunk / Boot First Row :	1284 L / 45.3 cu-ft

Trunk / Boot Second Row :	345 L / 12.2 cu-ft


Hyundai Matrix 2001 1.6 GLS Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Drums (- mm / - inches)

Front Tyres - Rims dimensions :	185/65 R14

Rear Tyres - Rims dimensions :	185/65 R14

Steering :	Rack and pinion

Turning circle :	11.3 m / 37.1 feet

Steering wheel lock-to-lock :	3.2 turns

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	MacPherson. Coil Springs. Anti-roll bar.

What engine is in Hyundai Matrix 2001 1.6 GLS?
The Hyundai Matrix 2001 1.6 GLS has a Inline 4, Petrol engine with 1599 cm³ / 97.6 cu-in capacity.

How many horsepower (hp) does a 2001 Hyundai Matrix 2001 1.6 GLS have?
The 2001 Hyundai Matrix 2001 1.6 GLS has 103 PS / 102 bhp / 76 kW.

How much does a Hyundai Matrix 2001 1.6 GLS weighs?
The Hyundai Matrix 2001 1.6 GLS weighs 1323 Kg / 2917 lbs.

What is the top speed of a Hyundai Matrix 2001 1.6 GLS?
The Hyundai Matrix 2001 1.6 GLS top speed is 170 Km/h / 106 mph.

Is Hyundai Matrix 2001 1.6 GLS All Wheel Drive (AWD)?
No, the Hyundai Matrix 2001 1.6 GLS is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).

How fast is a Hyundai Matrix 2001 1.6 GLS?
The Hyundai Matrix 2001 1.6 GLS can reach 0 to 100 km/h (0 to 62 mph) in 12.7 seconds and has a top speed of 170 km/h.
