Ford Scorpio I 2.9i Specs

(1992 - 1994) - Technical Specifications for Years 1992, 1993, 1994

Petrol

2935 cm³
179.1 cu-in

V 6

146 PS
144 HP / 107 kW

228 Nm
168 lb-ft

204 km/h
127 Mph

10.3 L/100 km
27 MPG UK
23 MPG US

Ford Scorpio I 2.9i Body, Model and Production details

Generation :	Scorpio 1

Body :	-

Num. of Doors :	4 doors


Ford Scorpio I 2.9i Engine Technical Data

Engine type - Number of cylinders :	V 6

Engine Code :	BRD/E/F

Fuel type :	Petrol

Fuel System :	MPI - Ford EEC-IV

Lubrication :	See oil information Ford Scorpio I 2.9i Oil Specifications - Engine oil All Weather: 5W30,0W40, 5W30 Engine oil capacity (with filter): 4.7 / 4.3 L
Engine Cooling - Capacity :	8.5 L / 8.98 quarts

Engine Alignment :	Longitudinal

Engine displacement :	2935 cm³ / 179.1 cu-in

Bore x Stroke :	93.0 x 72.0 mm 3.66 x 2.83 inches

Number of valves :	12 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	9.0

Horsepower :	146 PS / 144 HP / 107 kW @ 5500 rpm

Maximum torque :	228 Nm / 168 lb-ft @ 3000 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	5 speed Manual Transmission Relations Gearbox oil Gearbox oil type: 75W90 Gearbox oil capacity: 1.9 L


Ford Scorpio I 2.9i Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	10.3 L/100 km 27 MPG UK 23 MPG US

Range :	679 km / 422 miles

Fuel Tank Capacity :	70 L 18.5 US gallons 15.4 UK gallons


Ford Scorpio I 2.9i Size, Dimensions, Aerodynamics and Weight

Wheelbase :	276.0 cm / 108.66 inches

Length :	467.0 cm / 183.86 inches

Width :	176.0 cm / 69.29 inches

Height :	143.0 cm / 56.3 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1340 kg / 2954 lbs

Weight/Power Output Ratio :	9.2 kg/hp


Ford Scorpio I 2.9i Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	from 440 L / 15.5 cu-ft


Ford Scorpio I 2.9i Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Discs (- mm / - inches)

Front Tyres - Rims dimensions :	185/70 R14

Rear Tyres - Rims dimensions :	185/70 R14

Front Suspension :	Independent. MacPherson. Coil Springs. Anti-roll bar.

Rear Suspension :	Independent transverse arms. Coil Springs. Anti roll bar
