Make

Focus 3 Sportbreak (EU Market) Versions

Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Specs

(2011 - 2014) - Technical Specifications for Years 2011, 2012, 2013, 2014

Diesel

1560 cm³
95.2 cu-in

Inline 4

114 PS
112 HP / 84 kW

285 Nm
210 lb-ft

193 km/h
120 Mph

4.5 L/100 km
63 MPG UK
52 MPG US

Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Body, Model and Production details

Generation :	Focus 3

Body :	Estate

Num. of Doors :	5 doors


Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Diesel

Fuel System :	Direct Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	1560 cm³ / 95.2 cu-in

Bore x Stroke :	75.0 x 88.3 mm 2.95 x 3.48 inches

Number of valves :	8 Valves

Aspiration :	Turbo (TGV) + Intercooler

Compression Ratio :	16

Horsepower :	114 PS / 112 HP / 84 kW @ 3600 rpm

Maximum torque :	285 Nm / 210 lb-ft @ 1750-2500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio: 6th Gear Ratio: Reverse Gear Ratio: 8.4


Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	4.5 L/100 km 63 MPG UK 52 MPG US

Fuel Consumption - Economy - Combined NEDC :	4.5 L/100 km 63 MPG UK 52 MPG US

Range :	1177 km / 732 miles

Fuel Tank Capacity :	53 L 14 US gallons 11.7 UK gallons

CO2 emissions :	117 g/km (Ford)

Emission standard :	Euro V

Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Safety Ratings

Euro NCAP	Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Euro NCAP Safety Rating Adult: Pedestrian: Child: Safety Assist: 92 % 72 % 82 % 71 % Tested on: 2 / 2012

Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Performance

Top Speed :	193 km/h / 120 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	11.1 s


Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Size, Dimensions, Aerodynamics and Weight

Wheelbase :	264.8 cm / 104.25 inches

Length :	455.6 cm / 179.37 inches

Width :	182.3 cm / 71.77 inches

Height :	150.5 cm / 59.25 inches

Front Axle :	154.4 cm / 60.79 inches

Rear Axle :	155.9 cm / 61.38 inches

Aerodynamic drag coefficient - Cx :	-


Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Interior size, Dimensions

Num. of Seats :	5 seats

Seat distribution :	2+3

Trunk / Boot capacity :	490 L / 17.3 cu-ft

Trunk / Boot First Row :	1516 L / 53.5 cu-ft


Ford Focus 3 Sportbreak (EU Market) 1.6 TDCi 115HP Trend Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (278 mm / 10.94 inches)

Rear Brakes - Disc dimensions :	Discs (271 mm / 10.67 inches)

Front Tyres - Rims dimensions :	205/55 R16

Rear Tyres - Rims dimensions :	205/55 R16

Front Wheels Width :	6.5"

Rear Wheels Width :	6.5"

Steering :	Rack and pinion Electric

Steering wheel lock-to-lock :	2.6 turns

Steering ratio :	14.7

Front Suspension :	MacPherson struts. Coil springs.

Rear Suspension :	Coil Springs.
