Cortina Mk IV Versions

- 1300 (1976)- 1600 (1976)- 1600 Estate (1976)- 1600 Ghia (1976)- 1600 Ghia Estate (1976)- 1600 GL (1976)- 1600 GL Estate (1976)- 1600 LS (1976)- 1600 LS Estate (1976)- 2000 GL (1976)- 2000 GL Estate (1976)- 2300 Estate (1979)- 2300 GL (1977)

Ford Cortina Mk IV 1600 Ghia Specs

(1976 - ) Technical Specifications

Key Specs

Petrol

1593 cm³
97.2 cu-in

Inline 4

91 PS
90 HP / 67 kW

122 Nm
89 lb-ft

Compare with another car

More pictures

Ford Cortina Mk IV 1600 Ghia Body, Model and Production details

Generation :	Cortina Mark 4

Body :	Sedan

Num. of Doors :	4 doors


Ford Cortina Mk IV 1600 Ghia Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Petrol

Fuel System :	1 Weber carb

Engine Alignment :	Longitudinal

Engine displacement :	1593 cm³ / 97.2 cu-in

Bore x Stroke :	87.65 x 66.00 mm 3.45 x 2.6 inches

Number of valves :	8 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	9.20

Horsepower :	91 PS / 90 HP / 67 kW @ 5700 rpm

Maximum torque :	122 Nm / 89 lb-ft @ 5700 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	4 speed Manual Transmission Relations Final Drive Ratio: 3.89


Ford Cortina Mk IV 1600 Ghia Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	54.1 L 14.3 US gallons 11.9 UK gallons

Catalytic converter :	No

Ford Cortina Mk IV 1600 Ghia Performance

Top Speed :	- km/h / - Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Ford Cortina Mk IV 1600 Ghia Size, Dimensions, Aerodynamics and Weight

Wheelbase :	258 cm / 101.57 inches

Length :	438 cm / 172.44 inches

Width :	170 cm / 66.93 inches

Height :	136.1 cm / 53.58 inches

Front Axle :	144.5 cm / 56.89 inches

Rear Axle :	142.0 cm / 55.91 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1035 kg / 2282 lbs

Weight/Power Output Ratio :	11.4 kg/hp


Ford Cortina Mk IV 1600 Ghia Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Drums (- mm / - inches)

Front Tyres - Rims dimensions :	-/- R-

Rear Tyres - Rims dimensions :	-/- R-

Steering :	Rack and pinion. -

Front Suspension :	Coil springs.

Rear Suspension :	Coil Springs. Semi-trailing arm. Trailing arm. De-Dion axle.

What engine is in Ford Cortina Mk IV 1600 Ghia?
The Ford Cortina Mk IV 1600 Ghia has a Inline 4, Petrol engine with 1593 cm³ / 97.2 cu-in capacity.

How many horsepower (hp) does a 1976 Ford Cortina Mk IV 1600 Ghia have?
The 1976 Ford Cortina Mk IV 1600 Ghia has 91 PS / 90 bhp / 67 kW.

How much does a Ford Cortina Mk IV 1600 Ghia weighs?
The Ford Cortina Mk IV 1600 Ghia weighs 1035 Kg / 2282 lbs.

Is Ford Cortina Mk IV 1600 Ghia All Wheel Drive (AWD)?
No, the Ford Cortina Mk IV 1600 Ghia is not All Wheel Drive (AWD). It's Rear Wheel Drive (RWD).
