Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto Specs

(2023 - ) - Technical Specifications for Years 2023, 2024, 2025

Key Specs

Diesel

1995 cm³
121.7 cu-in

Inline 4

210 PS
207 HP / 154 kW

500 Nm
368 lb-ft

180 km/h
112 Mph

10.6 L/100 km
27 MPG UK
22 MPG US

Compare with another car

More pictures

Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto Body, Model and Production details

Generation :	Ranger 4th Gen. (P703) - 2024 New Model

Body :	Pick-Up

Num. of Doors :	4 doors


Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Diesel

Fuel System :	Common Rail

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	1995 cm³ / 121.7 cu-in

Bore x Stroke :	84.01 x 90.03 mm 3.31 x 3.54 inches

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Horsepower :	210 PS / 207 HP / 154 kW @ - rpm

Maximum torque :	500 Nm / 368 lb-ft @ - rpm

Drive wheels - Traction - Drivetrain :	AWD

Transmission Gearbox - Number of speeds :	10 speed Automatic


Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Low WLTP:	12.7 L/100 km 22 MPG UK 19 MPG US

Fuel Consumption - Economy - Medium WLTP:	10.2 L/100 km 28 MPG UK 23 MPG US

Fuel Consumption - Economy - High WLTP:	9.2 L/100 km 31 MPG UK 26 MPG US

Fuel Consumption - Economy - Extra high WLTP:	11.3 L/100 km 25 MPG UK 21 MPG US

Fuel Consumption - Economy - Combined WLTP:	10.6 L/100 km 27 MPG UK 22 MPG US

Range (WLTP):	754 km / 469 miles

Fuel Tank Capacity :	80 L 21.1 US gallons 17.6 UK gallons

CO2 emissions WLTP :	278 g/km (Ford)

Catalytic converter :	Particle Filter (with SCR cat.)

Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto Performance

Top Speed :	180 km/h / 112 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto Size, Dimensions, Aerodynamics and Weight

Wheelbase :	327.0 cm / 128.74 inches

Length :	538.1 cm / 211.85 inches

Width :	196.8 cm / 77.48 inches

Width with mirrors :	220.8 cm / 86.93 inches

Height :	192.2 cm / 75.67 inches

Ground clearance :	26.6 cm / 10.47 inches

Approach angle (deg) :	32.0°

Breakover (Rampover) angle (deg) :	24.0°

Departure angle (deg) :	27.0°

Max. Towing Capacity Weight :	2500 kg / 5512 lbs

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	2436 kg / 5370 lbs

Weight/Power Output Ratio :	11.6 kg/hp


Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto Interior size, Dimensions

Num. of Seats :	5 seats

Trunk / Boot capacity :	-


Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Discs (- mm / - inches)

Front Tyres - Rims dimensions :	285/70 R17

Rear Tyres - Rims dimensions :	285/70 R17

Turning circle :	13.0 m / 42.7 feet

Front Suspension :	Double wishbone. Coil Springs. Anti-roll bar.

Rear Suspension :	Rigid axle. Coil Springs.

What engine is in Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto?
The Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto has a Inline 4, Diesel engine with 1995 cm³ / 121.7 cu-in capacity.

How many horsepower (hp) does a 2023 Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto have?
The 2023 Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto has 210 PS / 207 bhp / 154 kW.

How much does a Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto weighs?
The Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto weighs 2436 Kg / 5370 lbs.

What is the top speed of a Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto?
The Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto top speed is 180 Km/h / 112 mph.

Is Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto All Wheel Drive (AWD)?
Yes, the Ford Ranger Raptor 2.0 EcoBlue e-4WD Auto is All Wheel Drive (AWD).
