Make

Ducato L1H2 2016 Versions

- 120 Multijet 30 (2019)- 140 Multijet 30 (2019)- 160 Multijet 30 (2019)- 180 Multijet 30 (2019)

Fiat Ducato L1H2 2016 180 Multijet 30 Specs

(2019 - 2021) - Technical Specifications for Years 2019, 2020, 2021

Key Specs

Diesel

2287 cm³
139.6 cu-in

Inline 4

178 PS
176 HP / 131 kW

450 Nm
331 lb-ft

Compare with another car

More pictures

Fiat Ducato L1H2 2016 180 Multijet 30 Body, Model and Production details

Generation :	Ducato (X290) - 2015 Update

Body :	Van

Num. of Doors :	4 doors


Fiat Ducato L1H2 2016 180 Multijet 30 Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	F1AGL411B

Fuel type :	Diesel

Fuel System :	Common Rail

Lubrication :	See oil information Fiat Ducato L1H2 2016 180 Multijet 30 Oil Specifications - Engine oil All Weather: 0W30 API/ACEA: C2 Engine oil capacity (with filter): 5.9 L

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	2287 cm³ / 139.6 cu-in

Bore x Stroke :	88.0 x 94.0 mm 3.46 x 3.7 inches

Number of valves :	16 Valves

Aspiration :	Turbo Intercooler

Compression Ratio :	16.2

Horsepower :	178 PS / 176 HP / 131 kW @ 3500 rpm

Maximum torque :	450 Nm / 331 lb-ft @ 1500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	6 speed Manual


Fiat Ducato L1H2 2016 180 Multijet 30 Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	9 L/100 km 31 MPG UK 26 MPG US

Fuel Consumption - Economy - Open road NEDC :	7.3 L/100 km 39 MPG UK 32 MPG US

Fuel Consumption - Economy - Combined NEDC :	7.9 L/100 km 36 MPG UK 30 MPG US

Range :	949 km / 590 miles

Fuel Tank Capacity :	75 L 19.8 US gallons 16.5 UK gallons

AdBlue Tank :	19 L 5 US gallons 4.2 UK gallons

CO2 emissions :	209 g/km (Fiat)

Catalytic converter :	Particle Filter (with SCR cat.)

Fiat Ducato L1H2 2016 180 Multijet 30 Performance

Top Speed :	- km/h / - Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Fiat Ducato L1H2 2016 180 Multijet 30 Size, Dimensions, Aerodynamics and Weight

Wheelbase :	300.0 cm / 118.11 inches

Length :	496.3 cm / 195.39 inches

Width :	205.0 cm / 80.71 inches

Height :	252.4 cm / 99.37 inches

Front Axle :	181.0 cm / 71.26 inches

Rear Axle :	179.0 cm / 70.47 inches

Ground clearance :	16.2 cm / 6.38 inches

Cargo box inside length :	267.0 cm / 105.12 inches

Cargo box inside height :	193.2 cm / 76.06 inches

Cargo width :	187.0 cm / 73.62 inches

Max. width at wheelhouse :	142.2 cm / 55.98 inches

Rear door width :	156.2 cm / 61.5 inches

Rear door height :	179.0 cm / 70.47 inches

Side door width :	107.5 cm / 42.32 inches

Side door height :	175.5 cm / 69.09 inches

Max. Towing Capacity Weight :	2500 kg / 5512 lbs

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1940 kg / 4277 lbs

Weight/Power Output Ratio :	10.9 kg/hp


Fiat Ducato L1H2 2016 180 Multijet 30 Interior size, Dimensions

Num. of Seats :	3 seats

Trunk / Boot capacity :	9500 L / 335.5 cu-ft

Trunk / Boot First Row :	9500 L / 335.5 cu-ft


Fiat Ducato L1H2 2016 180 Multijet 30 Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Discs (- mm / - inches)

Front Tyres - Rims dimensions :	215/70 R15

Rear Tyres - Rims dimensions :	215/70 R15

Turning circle :	11.3 m / 37.1 feet

Front Suspension :	Independent, McPherson type with wishbones, coil springs, telescopic shock absorbers and anti-roll bar

Rear Suspension :	Rigid tubular axle and longitudinal parabolic leaf springs, telescopic shock absorbers and flexible side buffers

What engine is in Fiat Ducato L1H2 2016 180 Multijet 30?
The Fiat Ducato L1H2 2016 180 Multijet 30 has a Inline 4, Diesel engine with 2287 cm³ / 139.6 cu-in capacity.

How many horsepower (hp) does a 2019 Fiat Ducato L1H2 2016 180 Multijet 30 have?
The 2019 Fiat Ducato L1H2 2016 180 Multijet 30 has 178 PS / 176 bhp / 131 kW.

How much does a Fiat Ducato L1H2 2016 180 Multijet 30 weighs?
The Fiat Ducato L1H2 2016 180 Multijet 30 weighs 1940 Kg / 4277 lbs.

Is Fiat Ducato L1H2 2016 180 Multijet 30 All Wheel Drive (AWD)?
No, the Fiat Ducato L1H2 2016 180 Multijet 30 is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).
