Fiat Doblò 2024 MultiCab L2 1.5 BlueHDi Body, Model and Production details
|
|
| Generation : | Doblò (Typ K9) - 2024 Facelift |
| Body : | Van |
| Num. of Doors : | 5 doors |
Fiat Doblò 2024 MultiCab L2 1.5 BlueHDi Engine Technical Data
|
|
| Engine type - Number of cylinders : | Inline 4 |
| Engine Code : | PSA BlueHDI YH01 DV5RD |
| Fuel type : | Diesel |
| Fuel System : | Common Rail |
| Lubrication : |
See oil information  Fiat Doblò 2024 MultiCab L2 1.5 BlueHDi Oil Specifications - Engine oil All Weather: 0W20 OEM: PSA B71 2010 API/ACEA: ACEA C6 Engine oil capacity (with filter): 4.0 L |
| Engine Alignment : | Transverse |
| Engine Position : | Front |
| Engine displacement : | 1499 cm3 / 91.5 cu-in |
| Bore x Stroke : |
75 x 84.8 mm 2.95 x 3.34 inches |
| Number of valves : | 16 Valves |
| Aspiration : | Turbo Intercooler |
| Compression Ratio : | 16.5 |
| Horsepower : |
102 PS / 101 HP / 75 kW @ 3500 rpm |
| Maximum torque : |
250 Nm / 184 lb-ft @ 1750 rpm |
| Drive wheels - Traction - Drivetrain : | FWD |
| Transmission Gearbox - Number of speeds : |
6 speed Manual
|
Fiat Doblò 2024 MultiCab L2 1.5 BlueHDi Fuel Consumption (Economy), Emissions and Range
|
|
| Fuel Consumption - Economy - Low WLTP: |
5.3 L/100 km 53 MPG UK 44 MPG US |
| Fuel Consumption - Economy - Medium WLTP: |
4.6 L/100 km 61 MPG UK 51 MPG US |
| Fuel Consumption - Economy - High WLTP: |
4.5 L/100 km 63 MPG UK 52 MPG US |
| Fuel Consumption - Economy - Extra high WLTP: |
6.1 L/100 km 46 MPG UK 39 MPG US |
| Fuel Consumption - Economy - Combined WLTP: |
5.2 L/100 km 54 MPG UK 45 MPG US |
| Range (WLTP): | 1019 km / 633 miles |
| Fuel Tank Capacity : |
53 L 14 US gallons 11.7 UK gallons |
| AdBlue Tank : |
17 L 4.5 US gallons 3.7 UK gallons |
| CO2 emissions WLTP : | 136 g/km (Fiat) |
| Catalytic converter : | Particle Filter (with SCR cat.) |
Fiat Doblò 2024 MultiCab L2 1.5 BlueHDi Performance
|
|
| Top Speed : | 150 km/h / 93 Mph |
| Acceleration 0 to 100 km/h (0 to 62 mph) : | - s |
Fiat Doblò 2024 MultiCab L2 1.5 BlueHDi Size, Dimensions, Aerodynamics and Weight
|
|
| Wheelbase : | 297.5 cm / 117.13 inches |
| Length : | 475.3 cm / 187.13 inches |
| Width : | 184.8 cm / 72.76 inches |
| Width with mirrors : | 210.7 cm / 82.95 inches |
| Height : | 181.2 cm / 71.34 inches |
| Front Axle : | 153.3 cm / 60.35 inches |
| Rear Axle : | 156.7 cm / 61.69 inches |
| Ground clearance : | 16.0 cm / 6.3 inches |
| Cargo box inside length : | 145.0 cm / 57.09 inches |
| Cargo box inside height : | 124.3 cm / 48.94 inches |
| Cargo width : | 152.7 cm / 60.12 inches |
| Max. width at wheelhouse : | 122.9 cm / 48.39 inches |
| Loading height : | 56.0 cm / 22.05 inches |
| Rear door width : | 124.1 cm / 48.86 inches |
| Rear door height : | 119.6 cm / 47.09 inches |
| Side door width : | 67.5 cm / 26.57 inches |
| Side door height : | 107.2 cm / 42.2 inches |
| Max. Towing Capacity Weight : | 1080 kg / 2381 lbs |
| Aerodynamic drag coefficient - Cx : | - |
| Curb Weight : | 1523 kg / 3358 lbs |
| Weight/Power Output Ratio : | 14.9 kg/hp |
Fiat Doblò 2024 MultiCab L2 1.5 BlueHDi Interior size, Dimensions
|
|
| Num. of Seats : | 5 seats |
| Trunk / Boot capacity : | 1800 L / 63.6 cu-ft |
| Trunk / Boot First Row : | 3500 L / 123.6 cu-ft |
Fiat Doblò 2024 MultiCab L2 1.5 BlueHDi Brakes, Tires, Steering and Suspension
|
|||
| Front Brakes - Disc dimensions : |
Vented Discs (283 mm / 11.14 inches) |
||
| Rear Brakes - Disc dimensions : |
Discs (268 mm / 10.55 inches) |
||
| Front Tyres - Rims dimensions : | 205/60 R16 | ||
| Rear Tyres - Rims dimensions : | 205/60 R16 | ||
| Turning circle : | 11.9 m / 39 feet | ||
| Front Suspension : | MacPherson. Coil Springs. Anti-roll bar. | ||
| Rear Suspension : | Beam Axle. Coil Springs. | ||
