Chrysler Voyager 3rd Generation 2.5 TD Specs

(1996 - 2000) - Technical Specifications for Years 1996, 1997, 1998, 1999, 2000

Key Specs

Diesel

2499 cm³
152.5 cu-in

Inline 4

115 PS
113 HP / 85 kW

262 Nm
193 lb-ft

174 km/h
108 Mph

8.6 L/100 km
33 MPG UK
27 MPG US

Compare with another car

More pictures

Chrysler Voyager 3rd Generation 2.5 TD Body, Model and Production details

Generation :	Voyager 3rd Generation

Body :	MPV

Num. of Doors :	5 doors


Chrysler Voyager 3rd Generation 2.5 TD Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	VM 425 OHV

Fuel type :	Diesel

Fuel System :	Indirect Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	2499 cm³ / 152.5 cu-in

Bore x Stroke :	92.0 x 94.0 mm 3.62 x 3.7 inches

Number of valves :	8 Valves

Aspiration :	Turbo

Compression Ratio :	21.0

Horsepower :	115 PS / 113 HP / 85 kW @ 4000 rpm

Maximum torque :	262 Nm / 193 lb-ft @ 1800 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	5 speed Manual Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio:


Chrysler Voyager 3rd Generation 2.5 TD Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - Combined:	8.6 L/100 km 33 MPG UK 27 MPG US

Fuel Consumption - Economy - Open road:	5.9 L/100 km 48 MPG UK 40 MPG US

Fuel Consumption - Economy - Highway:	6.9 L/100 km 41 MPG UK 34 MPG US

Fuel Consumption - Economy - City:	11.8 L/100 km 24 MPG UK 20 MPG US

Range :	872 km / 542 miles

Fuel Tank Capacity :	75 L 19.8 US gallons 16.5 UK gallons

Chrysler Voyager 3rd Generation 2.5 TD Performance

Top Speed :	174 km/h / 108 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	13.2 s


Chrysler Voyager 3rd Generation 2.5 TD Size, Dimensions, Aerodynamics and Weight

Wheelbase :	287.8 cm / 113.31 inches

Length :	473.3 cm / 186.34 inches

Width :	195.0 cm / 76.77 inches

Height :	182.0 cm / 71.65 inches

Front Axle :	160.0 cm / 62.99 inches

Rear Axle :	162.6 cm / 64.02 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1705 kg / 3759 lbs

Weight/Power Output Ratio :	14.8 kg/hp


Chrysler Voyager 3rd Generation 2.5 TD Interior size, Dimensions

Num. of Seats :	7 seats

Seat distribution :	2+3+2

Trunk / Boot capacity :	450 L / 15.9 cu-ft

Trunk / Boot First Row :	4140 L / 146.2 cu-ft


Chrysler Voyager 3rd Generation 2.5 TD Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (- mm / - inches)

Rear Brakes - Disc dimensions :	Drums (- mm / - inches)

Front Tyres - Rims dimensions :	215/65 R15

Rear Tyres - Rims dimensions :	215/65 R15

Front Wheels Width :	6.5"

Rear Wheels Width :	6.5"

Steering :	Rack and pinion

Steering wheel lock-to-lock :	3.1 turns

Front Suspension :	MacPherson struts. Coil springs.

Rear Suspension :	Beam axle.

What engine is in Chrysler Voyager 3rd Generation 2.5 TD?
The Chrysler Voyager 3rd Generation 2.5 TD has a Inline 4, Diesel engine with 2499 cm³ / 152.5 cu-in capacity.

How many horsepower (hp) does a 1996 Chrysler Voyager 3rd Generation 2.5 TD have?
The 1996 Chrysler Voyager 3rd Generation 2.5 TD has 115 PS / 113 bhp / 85 kW.

How much does a Chrysler Voyager 3rd Generation 2.5 TD weighs?
The Chrysler Voyager 3rd Generation 2.5 TD weighs 1705 Kg / 3759 lbs.

What is the top speed of a Chrysler Voyager 3rd Generation 2.5 TD?
The Chrysler Voyager 3rd Generation 2.5 TD top speed is 174 Km/h / 108 mph.

Is Chrysler Voyager 3rd Generation 2.5 TD All Wheel Drive (AWD)?
No, the Chrysler Voyager 3rd Generation 2.5 TD is not All Wheel Drive (AWD). It's Front Wheel Drive (FWD).

How fast is a Chrysler Voyager 3rd Generation 2.5 TD?
The Chrysler Voyager 3rd Generation 2.5 TD can reach 0 to 100 km/h (0 to 62 mph) in 13.2 seconds and has a top speed of 174 km/h.
