Make

Townsman 1969 Versions

Chevrolet Townsman 1969 327 V8 Turbo-Fire Powerglide 2-speed Specs

(1968 - 1969) - Technical Specifications for Years 1968, 1969

Petrol

5354 cm³
326.7 cu-in

V 8

238 PS
235 HP / 175 kW

441 Nm
325 lb-ft

Chevrolet Townsman 1969 327 V8 Turbo-Fire Powerglide 2-speed Body, Model and Production details

Generation :	Townsman 1969

Body :	Estate

Num. of Doors :	5 doors


Chevrolet Townsman 1969 327 V8 Turbo-Fire Powerglide 2-speed Engine Technical Data

Engine type - Number of cylinders :	V 8

Engine Code :	GM LF7/L30 327

Fuel type :	Petrol

Fuel System :	Carburetor

Lubrication :	See oil information Engine oil capacity (with filter): 3.8 L
Engine Cooling - Capacity :	16.1 L / 17.01 quarts

Engine Alignment :	Longitudinal

Engine Position :	Front

Engine displacement :	5354 cm³ / 326.7 cu-in

Bore x Stroke :	101.6 x 82.6 mm 4 x 3.25 inches

Number of valves :	16 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	9.0

Horsepower :	238 PS / 235 HP / 175 kW @ 4800 rpm

Maximum torque :	441 Nm / 325 lb-ft @ 2800 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	2 speed Automatic Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: Reverse Gear Ratio: 1.77 Final Drive Ratio: 3.36


Chevrolet Townsman 1969 327 V8 Turbo-Fire Powerglide 2-speed Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	95 L 25.1 US gallons 20.9 UK gallons

Chevrolet Townsman 1969 327 V8 Turbo-Fire Powerglide 2-speed Performance

Top Speed :	- km/h / - Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	- s


Chevrolet Townsman 1969 327 V8 Turbo-Fire Powerglide 2-speed Size, Dimensions, Aerodynamics and Weight

Wheelbase :	302.3 cm / 119.02 inches

Length :	550.4 cm / 216.69 inches

Width :	202.7 cm / 79.8 inches

Height :	145.0 cm / 57.09 inches

Front Axle :	158.8 cm / 62.52 inches

Rear Axle :	158.5 cm / 62.4 inches

Ground clearance :	16.0 cm / 6.3 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1954 kg / 4308 lbs

Weight/Power Output Ratio :	8.2 kg/hp


Chevrolet Townsman 1969 327 V8 Turbo-Fire Powerglide 2-speed Interior size, Dimensions

Num. of Seats :	6 seats

Seat distribution :	3+3

Front legroom :	108.2 cm / 42.6 inches

Rear seat legroom :	97.8 cm / 38.5 inches

Front head room :	98.8 cm / 38.9 inches

Rear head room :	97.8 cm / 38.5 inches

Trunk / Boot capacity :	-


Chevrolet Townsman 1969 327 V8 Turbo-Fire Powerglide 2-speed Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Drums (- mm / - inches)

Rear Brakes - Disc dimensions :	Drums (- mm / - inches)

Front Tyres - Rims dimensions :	8.55/- R14

Rear Tyres - Rims dimensions :	8.55/- R14

Turning circle :	13.3 m / 43.6 feet

Front Suspension :	Independent. Wishbone. Coil Springs.

Rear Suspension :	Rigid Axle. Coil Springs.
