Browse Car Specifications...

E10 Versions

BMW E10 2002 Tii Specs

(1968 - ) Technical Specifications

Petrol

1991 cm³
121.5 cu-in

Inline 4

132 PS
130 HP / 97 kW

178.0 Nm
131 lb-ft

193 km/h
120 Mph

BMW E10 2002 Tii Body, Model and Production details

Body :	Sedan

Num. of Doors :	2 doors


BMW E10 2002 Tii Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Petrol

Fuel System :	Kugelfischer fuel inj.

Engine Alignment :	Longitudinal

Engine displacement :	1991 cm³ / 121.5 cu-in

Bore x Stroke :	89.00 x 80.00 mm 3.5 x 3.15 inches

Number of valves :	8 Valves

Aspiration :	naturally-aspirated

Compression Ratio :	10.00

Horsepower :	132 PS / 130 HP / 97 kW @ 5800 rpm

Maximum torque :	178.0 Nm / 131 lb-ft @ 4500 rpm

Drive wheels - Traction - Drivetrain :	RWD

Transmission Gearbox - Number of speeds :	4 speed Manual Transmission Relations Final Drive Ratio: 3.45


BMW E10 2002 Tii Fuel Consumption (Economy), Emissions and Range

Fuel Tank Capacity :	46 L 12.2 US gallons 10.1 UK gallons

Catalytic converter :	No


BMW E10 2002 Tii Size, Dimensions, Aerodynamics and Weight

Wheelbase :	250.2 cm / 98.5 inches

Length :	422.9 cm / 166.5 inches

Width :	156.2 cm / 61.5 inches

Height :	141 cm / 55.51 inches

Front Axle :	134.8 cm / 53.07 inches

Rear Axle :	134.8 cm / 53.07 inches

Ground clearance :	16.0 cm / 6.3 inches

Aerodynamic drag coefficient - Cx :	-

Curb Weight :	1026 kg / 2262 lbs

Weight/Power Output Ratio :	7.8 kg/hp


BMW E10 2002 Tii Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Discs (256 mm / 10.08 inches)

Rear Brakes - Disc dimensions :	Drums (- mm / - inches)

Front Tyres - Rims dimensions :	-/- R-

Rear Tyres - Rims dimensions :	-/- R-

Steering :	Endless screw. -

Front Suspension :	Coil springs. Lower wishbone. Anti-roll bar.

Rear Suspension :	Coil Springs. Semi-trailing arm. Trailing arm. Anti-roll bar.
