Make

TT (8J) Versions

Audi TT (8J) 1.8 TFSI S tronic Specs

(2010 - 2012) - Technical Specifications for Years 2010, 2011, 2012

Petrol

1798 cm³
109.7 cu-in

Inline 4

160 PS
158 HP / 118 kW

250 Nm
184 lb-ft

226 km/h
140 Mph

Audi TT (8J) 1.8 TFSI S tronic Body, Model and Production details

Generation :	Type 8J

Body :	Coupe

Num. of Doors :	2 doors


Audi TT (8J) 1.8 TFSI S tronic Engine Technical Data

Engine type - Number of cylinders :	Inline 4

Engine Code :	-

Fuel type :	Petrol

Fuel System :	Direct Injection.

Engine Alignment :	Transverse

Engine Position :	Front

Engine displacement :	1798 cm³ / 109.7 cu-in

Bore x Stroke :	82.5 x 84.1 mm 3.25 x 3.31 inches

Number of valves :	16 Valves

Aspiration :	Turbo + Intercooler

Compression Ratio :	10

Horsepower :	160 PS / 158 HP / 118 kW @ 4500-6200 rpm

Maximum torque :	250 Nm / 184 lb-ft @ 1500-4500 rpm

Drive wheels - Traction - Drivetrain :	FWD

Transmission Gearbox - Number of speeds :	7 speed Automatic Transmission Relations 1st Gear Ratio: 2nd Gear Ratio: 3rd Gear Ratio: 4th Gear Ratio: 5th Gear Ratio: 6th Gear Ratio: 7th Gear Ratio: Reverse Gear Ratio: 6.9

Clutch Type :	Dual single-disc dry clutch


Audi TT (8J) 1.8 TFSI S tronic Fuel Consumption (Economy), Emissions and Range

Fuel Consumption - Economy - City NEDC :	8.4 L/100 km 34 MPG UK 28 MPG US

Fuel Consumption - Economy - Open road NEDC :	5.2 L/100 km 54 MPG UK 45 MPG US

Fuel Consumption - Economy - Combined NEDC :	6.4 L/100 km 44 MPG UK 37 MPG US

CO2 emissions :	147 g/km (Audi)

Emission standard :	Euro V

Audi TT (8J) 1.8 TFSI S tronic Performance

Top Speed :	226 km/h / 140 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) :	7.1 s


Audi TT (8J) 1.8 TFSI S tronic Size, Dimensions, Aerodynamics and Weight

Wheelbase :	246.8 cm / 97.17 inches

Length :	418.7 cm / 164.84 inches

Width :	184.2 cm / 72.52 inches

Height :	135.3 cm / 53.27 inches

Front Axle :	156.2 cm / 61.5 inches

Rear Axle :	154.8 cm / 60.94 inches

Aerodynamic drag coefficient - Cx :	0.30

Curb Weight :	1335 kg / 2943 lbs

Weight/Power Output Ratio :	8.3 kg/hp


Audi TT (8J) 1.8 TFSI S tronic Interior size, Dimensions

Num. of Seats :	4 seats

Seat distribution :	2+2

Trunk / Boot capacity :	292 L / 10.3 cu-ft

Trunk / Boot First Row :	700 L / 24.7 cu-ft


Audi TT (8J) 1.8 TFSI S tronic Brakes, Tires, Steering and Suspension

Front Brakes - Disc dimensions :	Vented Discs (312 mm / 12.28 inches)

Rear Brakes - Disc dimensions :	Discs (286 mm / 11.26 inches)

Front Tyres - Rims dimensions :	225/55 R16

Rear Tyres - Rims dimensions :	225/55 R16

Front Wheels Width :	7.5"

Rear Wheels Width :	7.5"

Steering :	Rack and pinion Electric

Steering ratio :	16.9

Front Suspension :	MacPherson struts. Coil springs.

Rear Suspension :	Coil Springs.
